Specifications
Dust collector machine1.Automatic dust
2.wide percolated area
3.high efficient
4.receycled using
2014 Hot sale automatic explosion proof dust collector
Dust collector machine
1.Automatic dust
2.wide percolated area
3.high efficient
4.receycled using
Porducts Name:
ZY-LGZ high efficient, automatic soot cleaning Percolate-type dust collect
Model Number :
ZY-LGZ
Advantage:
1.Automatic dust
2.wide percolated area
3.high efficient
4.receycled using
5.water proof
6.Oil proof7. antistatic(Especial for Al,Zn)
8.Anti-expolsion
9.Please contact us for more information
WIDELY USED:
ZY-LGZ high efficient, automatic soot cleaning Percolate-type dust collect,is widely used in polishing machine ,grinding machine ,belt sander , Mechanical processing , Casting, cement, rubber, food, pharmaceutical, ceramics and other industries
Sructural Principle:
Percolate-type dust collector has many advtanges,such as low resistance ,wide percolated area and small size.Set in a sole dust cleaning space with relevant tube connects dust collector .When connecting to a power source ,key on ,air with dust will into cupboard from covering ,through tubes and vent .Thick dust will be separated from air and dropped into drawer,as sdudden explosion of space and reduction of temperature.Other fine dust will be percolated and stayed on ektexine of core.by llision.hooking .and electrostatic interaction .Chlean air comes out through the vent.Air can be recycled and used dirctory in roon after cleaning treatment,without any energy lost during ventilation .We used an electromagnetic pulse device to clean dust.even when machine on.only power resources needs .
Technical parameters :
| Model | Filter area |
Filter speed (m/min) |
Parameters (M3/h) |
Power (KW) |
resistance (Pa) |
| LT-1x2-20 | 20sqm | 0.8-1.2 | 960-1460 | 0.75x2 | <1000 |
| LT-1x2-28 | 27sqm | 0.8-1.2 | 1300-1980 | 1.5 | <1000 |
| LT-2x2-45 | 40sqm | 0.8-1.2 | 1920-2880 | 2.2 | <1000 |
| LT-2x2-55 | 54sqm | 0.8-1.2 | 2600-3880 | 3 | <1000 |
| LT-3x2-60 | 60sqm | 0.8-1.2 | 2880-4320 | 4 | <1000 |
| LT-3x2-80 | 80sqm | 0.8-1.2 | 3900-5820 | 5.5 | <1000 |
| Model |
Filter cartridge (qty) |
Filter cartridge (size) |
Power (KW) |
| LT-1x2-20 | 2 | 350x600 | 0.75x2 |
| LT-1x2-28 | 4 | 220x800 | 1.5 |
| LT-2x2-45 | 4 | 240x800 | 2.2 |
| LT-2x2-55 | 4 | 240x800 | 3 |
| LT-3x2-60 | 6 | 350x650 | 4 |
| LT-3x2-80 | 6 | 350x650 | 5.5 |
Dust collector machine. As usual we use original export packing cartons with wooden pallet outside .
NINGBO HAISHU RELI IMP &EXP COMPANY,Specialized in produce dust collector over 30 years , export to all over the world with best quality and one step service ,Varity of the styles and sizes fit for different countries clients requirements .Welcome to inquiry and visit our company ,we will provide best service and competitive price with good quality .
