ZY-LGZ Pulse Cartridge Automatic Explosion Proof Dust Collector

Five Features the latest design:

1,Explosion-Proof design:an increase of explosion-proof confriguration,preventing mars risks.

2,low noise operation:siliencer set noise to 65 decibels.

3,high-precision filter:high-precision filter,can capture 5um dust.

4,automatic cleaning maintenance:pulse automatic cleaning,extend cartridage life.5,pretreatment settings:prevent flames direct access,to ensure safe use.

Structual Principle

Cartridge filter,with a small resistance,large filtration area,covering the advantages of the province and so on.the unit is placed between independent dust,dust cover configured to connect the hose to make the connection with the dust,plug in the power,turn on the fan,the fan attraction,dust source by dust cover~~air inlet dust into the box pre-processing chamber,because the sudden expansion of the air flow,the flow rate suddenly decreases,the separation of large particles of dust in the air and setting under its own weight,and the remaning dust particles due to the cartridge sieve,collision,hook,static electricity and so on.were stranded in filter wall,the purified air efficiency filter cartridge,air purifier can be discharged directly after the indoor recycling,no ventilation heat(cold)loss.and the use of on-line cleaning method,cleaning process with no downtime.pulse cleaning,the user must bring their own gas source can be.

Advantage:

1.Automatic dust
2.wide percolated area
3.high efficient
4.receycled using

5.water proof

6.Oil proof7. antistatic(Especial for Al,Zn)

8.Anti-expolsion

9.Please contact us for more information

WIDELY USED:

 ZY-LGZ high efficient, automatic soot cleaning  Percolate-type dust collect,is widely used in polishing machine ,grinding machine  ,belt sander , Mechanical processing , Casting, cement, rubber, food, pharmaceutical, ceramics and other industries

Sructural Principle:

Percolate-type dust collector has many advtanges,such as low resistance ,wide percolated area and small size.Set in a sole dust cleaning space with relevant tube connects dust collector .When connecting to a power source ,key on ,air with dust will into cupboard from covering ,through tubes and vent .Thick dust will be separated from air and dropped into drawer,as sdudden explosion of space and reduction of temperature.Other fine dust will be percolated and stayed on ektexine of core.by llision.hooking .and electrostatic interaction .Chlean air comes out through the vent.Air can be recycled and used dirctory in roon after cleaning treatment,without any energy lost during ventilation .We used an electromagnetic pulse device to clean dust.even when machine on.only power resources needs .

Technical parameters :

  Dust collector machine. As usual we use original export packing cartons with wooden pallet outside .
