KODI High-speed Atomizer Amino acid Spray Dryer, Spray drying machine/equipment
1, LPG model centirfugal atomizer Amino acid spray dryer / Amino acid drying equipment/ spray drying machine
2, Liquid or slurry drying processor
3, Easy operation and control
4, Stainless steel
What is Amino acid
In chemistry, an amino acid is a molecule that contains both amine and carboxyl functional groups.
In biochemistry, this term refers to alpha-amino acids with the general formula H2NCHRCOOH, where R is an organic substituent.
In the alpha amino acids, the amino and carboxylate groups are attached to the same carbon, which is called the α-carbon.
The various alpha amino acids differ in which side chain (R group) is attached to their alpha carbon.
They can vary in size from just a hydrogen atom in glycine, through a methyl group in alanine, to a large heterocyclic group in tryptophan.
Beyond the amino acids that are found in all forms of life, many non-natural amino acids are also important.
The chelating agents EDTA and nitriloacetic acid are alpha amino acids that are industrially synthesized (sometimes from naturally occurring amino acids).
Alpha-amino acids are the building blocks of proteins.
A protein forms via the condensation of amino acids to form a chain of amino acid "residues" linked by peptide bonds.
Proteins are defined by their unique sequence of amino acid residues; this sequence is the primary structure of the protein.
Just as the letters of the alphabet can be combined to form an almost endless variety of words, amino acids can be linked in varying sequences to form a huge variety of proteins.
Twenty standard amino acids are used by cells in protein biosynthesis, and these are specified by the general genetic code.
These twenty amino acids are biosynthesized from other molecules, but organisms differ in which ones they can synthesize and which ones must be provided in their diet.
The ones that cannot be synthesized by an organism are called essential amino acids.
LPG Amino Acid Spray Dryer Description
KODI Amino acid spray dryer is a wide applied process in liquid process shaping and drying industry. Particularly it is suitable for producing powder, granule or block solid product from solution, emulsion, suspending liquid and pumped paste liquid. Therefore when the distribution of granule size, final moisture, bulk density, granule shape of finished product must be conformed to accuracy standard, the spray drying is an ideal process.
LPG Amino Acid Spray Dryer Application
It's widely used in foodstuff, pharmaceutical and chemical industrial, such as whey, egg powder, Amino acid , white egg, amino acid product, protein, blood, food flavor, food ingredients, pectin, carrageenan, spirulina, herbal extraction, pigment, cocoa, mushroom, PAC, malt dextrin, collagen, juice, yeast, Coffee, Creamer, coconut, milk, gelatin, gum and acacia etc.
LPG Working Principle of Amino Acid Spray Drying Machine
After filtering and heating, the hot fresh air enter into the air distributor at the top of drying chamber, distributed in spiral way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.
Details of LPG Amino Acid Spray Drying Equipment
Final Product of KODI LPG Amino Acid Spray Dryer
LPG Amino Acid Spray Dryer Technical Parameters
Model |
Amino acid Spray Dryer MODEL LPG- |
|||||
5 |
25 |
50 |
100 |
150 |
200-5000 |
|
Inlet air temperature |
≤ 350°C |
|||||
Outlet air temperature |
80-90°C |
|||||
Evaporate capacity (kg/h) |
5 |
25 |
50 |
100 |
150 |
200-5000 |
Atomizer type |
compressed air drive |
mechanical drive |
||||
Rotary speed |
25000 |
22000 |
21500 |
18000 |
18000 |
15000 |
Diameter of atomizer disc (mm) |
50 |
120 |
120 |
120 |
150 |
180-500 |
Heating source |
Electricity |
Electricity/LPG/ Natural gas/Oil/Steam |
Electricity/LPG/ Natural gas/Oil/Steam |
Electricity/LPG/ Natural gas/Oil/Steam |
Electricity/LPG/ Natural gas/Oil/Steam |
Electricity/LPG/ Natural gas/Oil/Steam |
Electric-heating power (kw) |
9 |
- |
- |
- |
- |
- |
Dry powder yield (%) |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
≥ 95 |
Successful Experience Overseas of KODI LPG Amino Acid Spray Drying Machine
LPG Amino acid spray dryer/drying machine has a very mature technology and process, and KODI company has rich overseas site installation experience and good after sale service .
Why Choose KODI
International high quality certification product chain
Manufacturer, more reasonable price
Solid technical support and after-sales service
Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)
Exports to more than 20 countries and regions, good customers feedback
One-stop service, customized exclusive project feasibility report
Changzhou KODI Machinery Co., Ltd. located in the birthplace of China drying equipment----Zhenglu Industrial Park, Changzhou City, Jiangsu Province which is 150km away from Shanghai city, with a comfortable environment and convenient transportation access.
KODI company is a professional manufacture of drying machine, which include Seaweed processing machine, Seaweed drying machine (Cottonii to carrageenan, Agar agar ), LPG Spray dryer, Food ingredients spray dryer, Industrial spray dryer, Amino acid spray dryer/ fruit juice spray drying machine, fruit juice spray drying equipment, Flavor spray dryer (Cocoa, Maltdextrin,Gum Acacia), Lab Spray dryer, Spray drying equipment,Gelatin processing machinery, Gelatin drying machine (Hide and bone),Gelatin production line. we also deal in high-quality fermentation tank, Bright tank , Extraction tank, concentration tank , evaporator and etc..
We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products conform to international standards, such as CE, SGS.
KODI company also has a lot of top talent which have more than 15years of work experience, include research, design, manufacture and after sale service. Our products sell to all of the world (such as China, Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Chile, Peru, Argentina, Russia, Ukraine, South Africa, Cameroon, Sudan, Syria) and also have the good cooperation with the foreign client and vendor.
We are sure that our high quality products and excellent services will be appreciated by the growing list of satisfied customers. Contacting us is the first step to build a long and successful business relationship with us. Welcome!
Pre-sale service
Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.
1. Introduce the product to the customer in detail, answer the question raised by customer carefully;
2.Make plans for choice according to the needs and special requirements of users in different sectors;
Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents as customer’s requirements.
After-sale service
Provide considerate services to minimize clients’ worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.
Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
3.Send every client a preferential quotation.
Special Notice:
In order to quota you the right LPG Amino acid spray dryer/ Amino acid spray drying machine with best price, we would like to get the following information include in your inquiry:
-What is the raw material? Material related characteristic? Does it corrosive, strong basicity, or highly acid? Please confirm.
-What is the capacity per hour you need (kg/h)?
-What is the initial moisture and final moisture of finished products you require to get?
-What about the maximum heat temperature of raw material?
-What kind of fuel you use to heat the dryer? Natural gas, electricity, fuel oil or steam?
-Which equipment material do you like prefer? SUS304, SUS316L or Carbon steel?
-Provide us your country’s electricity information, such as phases, voltage, HZ?
-How about dust collect requirements?
-Other special requirements?
Frequently Asked Questions
Q: Can I visit your factory?
A: Yes. Many domestic and international customers visit our factory every year. Our company is near Shanghai.It only takes you about 1 hour to get Changzhou.Or we can visit you in Shanghai.
Q: What’s the quality of your products?
A:Parts of our products come with best quality, and our products passed CE certification, exported to lots countries around the world, such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Argentina, Russia, South Africa, etc. You can rest assured with the quality absolutely.
Q: What to do if the machine has a problem?
A:24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.
Q: How long is the warranty of your equipment?
A: Our warranty period is one year generally.
Q: What is your payment term?
A: Our usual payment term is: 30% TT in advance, 70% TT before shipment. Other ways can also be received after we both sides discussion and agreement.
Q: Does your price include freight?
A: Our usual price is based on FOB Shanghai, if you request CIF, please give us your delivery port, and we will give you CIF price.
