ac dc Single Output Switching Power Supply S150

Name: ac dc Single Output Switching Power Supply S150
Brand: HUAJING
SKU: 118263471

US$ 1 - 100 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

HUAJING

Model Number:

S150

Zhejiang Huajing Rectifier Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name HUAJING

Model Number S150

Output Power 101 - 200W

Output Type Single

Input Voltage Other, 85- 132VAC/170 - 264VAC by switch 47 - 63Hz

Output Frequency 47-63Hz

Specifications

1.single output switch power supply S150 with CE2.Competitived price,Good quality,Shortest lead time 3.Sample order is available

105°C Output capacitor

High efficiency and low operation temperature

Soft-start current can reduce the AC input impact effect

With short-circuit and overload protection

100% full-load burn-in test

Installed with EMI filter, minimum wave

Model Performance	S-150-5	S-150-7.5	S-150-9	S-150-12	S-150-13.5	S-150-15	S-150-24	S-150-27	S-150-48
DC output voltage	5V	7.5V	9V	12V	13.5V	15V	24V	27V	48V
Output Voltage Tolerance (Note 2)	±2%	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Rated output current	30A	20A	16.7A	12.5A	11.2A	10A	6.5A	5.6A	3.2A
Output Current Range	0-30A	0-20A	0-16.7A	0-12.5A	0-11.2A	0-10A	0-6.5A	0-5.6A	0-3.2A
Ripple and noise (Note 3)	150mVp-p	150mVp-p	180mV	180mV	180mV	180mV	240mV	240mV	240mV
Into the line of stability (Note 4)	±0.5%	±0.5%	±0.3%	±0.3%	±0.3%	±0.3%	±0.2%	±0.2%	±0.2%
Load stability (Note 5)	±0.5%	±0.5%	±0.3%	±0.3%	±0.3%	±0.3%	±0.2%	±0.2%	±0.2%
DC output power	150W	150W	150.3W	150W	151.2W	150W	156W	151.2W	153.6W
Efficiency	70%	80%	80%	82%	83%	84%	85%	86%	87%
DC voltage adjustable range	4.5-5.5V	6-8.3V	8-10.4V	10.6-13.2V	12-15V	13.5-16.5V	21-28V	24-30V	43-53V
Input Voltage Range	85 ~ 132VAC/170 ~ 264VAC SELECTED BY SWITCH 47 ~ 63Hz
Input Current	3.2A/115V 1.6A/230V
Inrush Current	Current 35A/115V 60A/230V cold start
Leakage	<3.5mA/240VAC
Overload	105% ~ 150% Type: PULSING HICCUP SHUTDOWN RESET: Automatic recovery
Over Voltage Protection	115% ~ 135%							125%-145%	115%-135%
