9 Bar Air Compressor

Shanghai Orient Compressor Factory Co., Ltd.
9 Bar Air Compressor thumbnail-1
9 Bar Air Compressor photo-1
Negotiable MOQ: 3 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw
Configuration:
Stationary
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Screw
Configuration Stationary
Power Source AC Power
Lubrication Style Lubricated
Mute Yes
Place of Origin Shanghai, China
Brand Name ORIENT
Model Number OLG-180W
Voltage 50HZ OR 60HZ
Dimension(L*W*H) 1812*1237*1497MM
Weight 1400
Warranty 2 YEARS
After-sales Service Provided Overseas third-party support available

Specifications

1- Noise isolation design for the whole machine.
2- high-quality maiframe
3- efficient and reliable motor

screw air copressor  :



8 bar air compressor ,  OLG - 75



Typepower(KW/HP)Pressure(bar)air displacement(m3/min)weight(kg)output inferfacesize:L X W X H  (mm)
OLG-75A55/75

7

8

10

13

10.5

9.5

8.5

7.5

1400



G   1 1/2"

1812X1237X1497







NOTES: 1. A is the cooling type; W is the water cooling type  and  A (W)  is the wind and water

cooling  type;     AZ is the direct drive  series .





             2. There is the direct connection type with no gear for 22 KW, 37KW,55KW, 75KW, 90KW,

110KW, 132KW,185KW    and     250 KW .





               3.   There are the voltage levels of  380V , 6000V and 10000V , and it can be customized

according   to the requirement.







               4.  The soft starting and frequncy changing type can be made according to the requirement

of the  user .





 9 bar air compressor9 bar air compressor9 bar air compressor9 bar air compressor9 bar air compressor9 bar air compressor
