Help CenterHot Sale Semi Automatic Hydraulic Steel Tube Cutting Machine
Related Products
-
Hot Sale Semi Automatic Pneumatic Steel Tube Cutting MachineUS$ 1,400 - 1,500MOQ: 1 Set -
Metal Pipe Cutting Machine/Metal Tube Cutting Tools/ Steel Pipe Cold Cutting MachineUS$ 15,000 - 25,000MOQ: 1 Set
-
Stainless Steel Pipe/Tube Cutting MachineUS$ 15,000 - 25,000MOQ: 1 Set
-
Carbon Steel Pipe/tube Cutting Machine Automatic LineUS$ 15,000 - 25,000MOQ: 1 Set
-
CNC Steel Pipe Cutting Machine on Hot SaleUS$ 15,000 - 25,000MOQ: 1 Set
CTK-355AV
Main Features:
- Cutter up and down move adopts slide rail system.This linear guide rail is by precision grinding & laborscrapping. Lubricating oil can permeate interface directly.IF any wear, you can adjust the strip.It can maintain the stability of the saw blade,no gap,cutting tolerance guaranteed,low maintenance cost.
- The high efficiency reducing mechanism is used for eliminating backlash rebound and the heavy cutting saw blade enjoys longer service life.
- Firm charging structure, accurate action,floating type load support without damaging the work surface.
- The specially designed clamp features strong clamping, firmness, reliability and safety.
- Automatic circulation of coolant ensures smooth cut surface and longer service life for saw blade.
Standard Components:
1.Basic machine station
2.Oil pressure system
Specifications:
Model |
CTK-355AV |
|
Main Drive Motor |
1.8/3.0KW 380V 50HZ |
|
Blade Speed(RPM) |
52/104(A series)Or 26/52(B series) |
|
|
Saw Blade Size |
Diameter (mm) |
HSS250-350 |
Aperture (mm) |
32 |
|
Pin hole(mm) |
2×11×PCD63 |
|
Oil Pressure(Kg/cm2) |
25-35 |
|
Machine Size(L*W*H)(mm) |
800*1250*1950 |
|
Machine Net Weight (Kg) |
400(A series ) |
|
Cutting Capacity ( take mild steel as reference)
Model |
CTK-355AV |
|
Head Swivel |
90 |
45 |
Round tube |
110 |
110 |
Square tube |
100 X 100 |
95X95 |
Rectangle tube |
120 X 80 |
100X80 |
Solid Bar |
50 |
38 |
Square Bar |
38X38 |
38X38 |
1) Provide the technical paper materials for installment, maintenance, operation and so on;
2) Provide equipment's key element bill of materials;
3) Provide the technical training for the equipment operation attendants;
4) Provide the installment instruction and the debugging work of the equipment;
5) Provide the perpetual paid service after the quality guarantee period.
Chittak Machinery Co., Ltd. is located in Foshan city, which is one of the most well-known manufacturing bases in China.
The company's technology team is composed of a group of engineers who have earlier engaged in the pipe cutting machine research and development. Has been accumulating more than 10 years of manufacturing experience, and more than 50 capable technicians and skilled workers, now the company possesses perfect quality control system and modern management tools. We are able to present best quality product for the best prices with ensuring first-class after-sale service to all the customers from home and abroad.
Our main products include: pipe cutting machine, profile cutting machine, aluminium profile cutting machine, chamfering machine, metal saw blade sharpening machine, and circular metal saw blade, etc. Our high quality products and attentive service help to win a large number of loyal customers home and abroad. The equipments are sold to the domestic market, Russian, Ukraine, Japan, Thailand, Vietnam, Indonesia, India, Bangladesh, Turkey, Iran, Brazil, South Africa, Columbia, Argentina, Middle East countries, etc, serving more than 30 countries and regions.
Our mission is to serve the needs of our customers to the best by providing our high quality China-made machinery and best possible service and to exceed their expectations. we will strive to strengthen our capabilities and continue to innovate our machines to fulfill the present and future needs of our worldwide customers.We are dedicated to a long-term partnership with our customers.
Our Exhibitions & Customers:
Question 1: What is the machine?
Answer: it is steel tube metal cutting machine, or semi automatic cut off saw,
or high speed metal circular saw cutting machine, or hydraulic drive cutting machine etc
Question 2: What is its function?
Answer: It is a metal solid bar or rod, hollow tube or pipe, profile cutting machine,
it is used for cutting steel, stainless, copper, brass bars.
Question 3: What is its cutting methods?
Answer: it uses TCT or HSS cold circular saw blade to cut it, not uses band saw
blade, laser, plasma or other ways.
Question 4: What fields can it be applied to?
Answer: car, car parts, boats, forging, furniture, moulds, metal processing, hardware parts,
large machines, sports products, boats, construction products, etc
Contact:
Contact person: Mr. Ben Zhong
Mob: 0086 13500258762
Tel: 0086 757 83318888
