Home > Products > Battery Cell > Hot Sale!! !TOPBAND 20AH New Nano Prismatic LiFePO4 Cell
Hot Sale!! !TOPBAND 20AH New Nano Prismatic LiFePO4 Cell
- Shenzhen
- T/T
You May Like
-
TOPBAND 12Ah Prismatic LiFePO4 Cell
-
Hot Sale!!! TOPBAND 10Ah Prismatic LiFePO4 Cell
-
Top Salling!! !TOPBAND new nano 3.2V prismatic lithium iron phosphate cell 27ah 25ah 20ah 12ah 10ah for energy storage
-
Top Salling!! !TOPBAND 3.2V prismatic LiFePO4 cell 27ah 25ah 20ah 12ah 10ah for energy storage UPS Solar System
-
Top Salling!! !TOPBAND 3.2V prismatic LiFePO4 cell 27ah 25ah 20ah 12ah 10ah for energy storage systems backup systems
-
3.2V 25Ah LiFePO4 Prismatic Cells
Product Details
Place of Origin | Guangdong, China | Brand Name | TOPBAND | |
Model Number | TB-027070145C-20Ah | Type | Other, Lithium Iron Phosphate | |
Nominal Voltage | Other, 3.2V | Size | Prismatic | |
Nominal Capacity | 20 Ampere Hours |
Product Description
TOPBAND 20Ah Prismatic LiFePO4 Cell
Technical Parameter Sheet | |
Model | TB-027070145C-20Ah |
Type | LiFePO4 |
Nominal Voltage | 3.2V |
Typical Capacity | 20AH |
Internal Impedance(1kHz AC) | <10 mΩ |
Nominal Charge Voltage | 3.65 ± 0.05V |
Discharge Cut-off Voltage | 2.0 ± 0.05V |
Max. Charge Current | 20 A |
Max Continuous Discharge Current | 40 A |
Max Pulse Discharge Current | 60 A |
Charging Temperature | 0℃to 45℃ |
Discharging Temperature | -20℃ to 60℃ |
Storage Temperature | 5℃ to 35℃(Suggest 25±5℃) |
Dimension | 70*27*145 mm |
Weight | Approx 525 ± 20 g |
Cycles to 80% with 100%DOD | ≥3000 under 20 to 25℃ |
- High energy density
- About 1/3 the weight of lead-acid batteries
- Environment friendly, no pollution
- No memory effect, 2000 times cycle-life
- Safe and reliable, no explosion when piercing, no fire when over voltage
- Low self discharge.
- High power, maxiumu discharge current up to 5C
- Nice exterior
- Larger capacity
- Smaller internal impedance
- Standard dimension (easy to assemble)
- More safety
Features:
- Replacement lead-acid battery ( AGM battery / deep cycle battery / gel battery )
- RV, Solar Energy Storage ect.
- High energy density
- About 1/3 the weight of lead-acid batteries.
- Environment friendly, no pollution
- No memory effect, 2000 times cycle-life
- Safe and reliable, no explosion when piercing, no fire when over voltage
- Low self discharge
- High power, maximize discharge current up to5C
Application:
- Golf cart, Golf trolley, Solar System, UPS, Telecommunication Base Station, Marine, Energy Storge, Computer Room, Outdoor Portable Power Supply, RV camper / Caravan ect.
Payment:
- Price Terms: FOB Shenzhen, China.
- T/T, L/C Acceptable
- Small order, paid in advance.
- Large order, 50% in deposit before production starts, balance should be paid before shipment.
Shipping:
- Delivery: Air Freight, Sea Freight, Express
- Delivery Time: Within 10-35 working days after payment received.
- Lead time depends on quality ordered.
Service:
- Quick response within 24 hours.
- OEM & ODM orders are available.
- Warranty 2 years.
Certifications:
- CE, CB, UL, MSDS, ISO9001-2009, TS16949, ISO14001, OHSAS18001
Warning
- Do not immerse the battery into water or seawater
- Do not use leave or charge battery near a heat source such as fire or heater If the battery leaks or smells, move it away from open fire.The battery should be used after fully charged in the first use
- Do not inversely connect positive and negative polar
- Do not put the battery in fire or heat the battery
- Do not short-circuit the battery with wires or other metals
- Do not pierce the shell with nails or other sharp objects
- Do not hammer or tread the pack
- Do not disassemble the pack and battery in any way
- If the battery leaks and the electrolyte get into the eye, do not rub eye, instead rinse eye with clean water, and seek medical attention
Other Models:
Contact Information:
Contact Person: Ms. Sunny Xue (Overseas Sales Manager)
Tel: +86-755-27651888-6338
Fax: +86-755-27651888-6291
Mobile: +86-18823821213
Skype: sunny-xlh
Web:
http://lithium-battery.en.china.cn/
Add: TopbandIndustrial Park, Liyuan Industrial Zone, Shiyan, Bao'an District, China (P.C:518108).
Thank you very much for taking the time out to read and consider this. We cordially invite you to visit our factory and sincerely hope we could work with you in the near future.
