Help CenterSolar Working Station
Related Products
Specifications
Solar working station:Use menu-style touch key, find wide applications,operate concisely, originate multi-timing mode
1) This working station is specially designed for close-loop solar heating system
2) It includes automatic controller, circulation pump, expansion vessel,safe valve, relief air valve, pressure meter, copper piping and circulation shell
3) This working station makes solar system work automatically
4) The multifunction makes you comfortable to use this system
Components:
1) Circulation pump (WILO)
2) Flow meter(import from Switzerland)
3) Check valve
4) Manometer
5) Automatic controller
6) Expansion vessel
7)Safety valve
8) Ball valve
Solar working station for split solar water heater and big solar projects,such as swimming pool,hotel,school.
Companents function description
1.Operating Screen(LCD) Display operating menu
2.Pump speed regulation Three speed Levels available,offers different flow rate
3.Security valve protect the system against over-pressure
4.Manometer Display system pressure(Max.10bar,normal working pressure is approx.2bar)
5.Filling and flushing connector Through this connector medium can be pumped into solar system
6.Circulation pump WILO Star RS1516(110V or 220V)
7.Expansion vessel connector connect expansion vessel.Expansion vessel balances the system pressure.
8.Return flow copper material,left side.Max. working temperture 150 degrees,screw thread 1/2' (DN15) as
standard
9.Iput and output signals Temperature sensors,power cord and other outputs
