ac dynamo motor / electric motor dynamo
| TECHNICAL DATA | |
| Housing metrial: | Aluminum/cast iron |
| Output range: | 0.55KW~315KW |
| Pole: | 2/4/6 |
| Terminal Box: | Top/Side Mounted |
| Protection Class: | IP55 |
| Insulation Class: | F/H |
| Bearing: | SKF/NSK/Chinese |
| Frequency: | 50/60HZ |
| Efficiency Standard: | IEC60034-30 IE2 |
| Operating Conditions | |
| Ambient temperature: | -15º C~40º C |
| Altitude: | not exceed 1000m |
| Rated voltage: | 380V(at buyer' s option) |
| Rated frequency: | 50HZ 60HZ(at buyer' s option) |
| Cooling method: | IC 411 |
| Duty: | S1 |
ac dynamo motor / electric motor dynamo --Operation Conditions
| Ambient temperature | -15°c to 40 °c |
| Altitude | ≤1000m |
| Rated voltage | 380V, 400V, 415V, 220V, 230V, 240V, etc |
| Rated frequency | 50HZ, 60HZ, 50HZ/60HZ |
| Duty | Continuous(S1) |
| Insulation class | Class B, Class F |
| Protection class | IP44, IP54, IP55 |
| Cooling method | IC0141 |
ac dynamo motor / electric motor dynamo ----Technical Data
Y electric Motor-- Stallation size
| Frame size | 56,63,71,80,90,100,112,132,160,180,200,225,250,280,315,355 |
| Power range | Y& Y2 Series: 0.33HP-430HP (0.24KW-315KW |
| MS Series: 0.08HP-10HP(0.06KW-7.5KW) | |
| Speed | 2 poles, 4 poles, 6 poles, 8 poles, 10 poles |
ac dynamo motor / electric motor dynamo
ac dynamo motor / electric motor dynamo --More Electric Motors for selection
AC dynamo motor Warranty: 1 year . During the warranty period, our factory would be responsible for problems caused by quality of production or raw material, we will offer technical support or sending spare parts for replacement if need except the spare parts which required periodic maintenace, and the damages caused by incorrect man-made operation will fall outside the clause of warranty. After expiration, our company provides cost maintenance. Further terms could be negotiable!
If you are interested in the above products or would like to have more information, please visit our webiste or call us 0086-15860695366 (24 hrs online), we will get back to you as soon as possible!
