300kva Diesel Generator Set

300kva Diesel Generator Set thumbnail-1
300kva Diesel Generator Set thumbnail-2
300kva Diesel Generator Set photo-1
300kva Diesel Generator Set photo-2
US$ 1,999 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
I-MAX
Model Number:
300kva
Contact Supplier Request Quote Chat Now
Fuzhou I-Max Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name I-MAX
Model Number 300kva
Output Type AC Three Phase
Speed 1500rpm or 1800rpm
Frequency 50Hz or 60Hz
Rated Power 300kva
Rated Voltage 220V-440V
Rated Current as per power



300kva Diesel generator set

Product Description

300kva diesel generator set



General  Feature

* Applied for continuous power generation

* Diesel Generator Set Engine brand (China brand or international brand etc. optional)

* Diesel Generator set Alternator: Stamford, Leroy sommer, Marathon  etc.brand (optional)

* Heavy duty rubber anti-vibration mountings

* 12V / 24V starter batteries & connecting cables

* Generator Industrial silencer, Residential silencer (optional)

* 40oC radiator as standard, 50oC is optional

* Key start panel control system as standard, digital auto-start panel is optional

* Full range protection function and alarm shutdown feature.

* ATS, AMF( Optional )  * Circuit breaker

* Oil Filter-Air filter

* Base fuel tank for 8 hour running at 100% load (optional)


300kva Diesel generator set--Specification



Model Prime Power Standby Engine Fuel   (L/h) Open type Size & Weight
kw kva kw kva Optional Consumption L*W*H(mm) weight(kg)
iMP-10 7 9 7.7 9.6 403D-11G (WX) 2.6 1150*620*900 359
iMP-14 10 12.5 11 14 403D-15G (WX) 5.3 1150*620*900 380
iMP-22 16 20 17.6 22 404D-22G (WX) 6.8 1500*810*1180 460
iMP-30 22 27.5 24 30 404D-22TG (WX) 7.1 1500*810*1180 520
iMP-33 24 30 26.4 33 1103A-33G 7.1 1500*810*1280 650
iMP-50 36 45 40 50 1103A-33TG1 10.7 1730*810*1200 730
iMP-66 48 60 52.8 66 1103A-33TG2 13.9 1860*810*1285 780
iMP-88 64 80 70.4 88 1104A-44TG2(WX) 18.7 1860*810*1300 800
iMP-110 80 100 88 110 1104C-44TAG2(WX) 22.6 1860*810*1300 1099
iMP-150 108 135 120 150 1006TAG 31.5 2300*810*1600 1275
iMP-165 120 150 132 165 1106A-70TAG2(WX) 41 2300*810*1600 1300
iMP-200 144 180 160 200 1106A-70TAG3(WX) 40.2 2350*810*1350 1500
iMP-220 160 200 176 220 1106A-70TAG4(WX) 43.2 2200*960*1500 1650
iMP-275 200 250 220 275 1306C-E87TAG6 53 2600*960*1600 1795
iMP-330 240 300 264 330 1606A-E93TAG5 56 2800*1250*1600 2500
iMP-385 280 350 308 385 2206A-E13TAG2 71 3280*1150*1950 2590
iMP-450 320 400 352 450 2206A-E13TAG3 87 3280*1150*1950 2720
iMP-500 364 455 400 500 2506A-E15TAG1 95 3350*1120*1970 3120
iMP-550 400 500 440 550 2506A-E15TAG2 105 3350*1120*1970 3800
iMP-660 480 600 528 660 2806A-E18TAG1A 137 3450*1540*2160 3940
iMP-715 520 650 572 715 2806A-E18TAG2 143 3450*1540*2160 4600
iMP-825 600 750 660 825 4006-23TAG2A 163 3770*1700*2130 5300
iMP-880 640 800 704 880 4006-23TAG3A 165 3770*1700*2130 5400
iMP-990 720 900 792 990 4008TAG1A 195 4570*2050*2350 6900
iMP-1100 800 1000 880 1100 4008TAG2A 220 4570*2050*2350 7500
iMP-1375 1000 1250 1100 1375 4012-46TWG2A 265 4615*1800*2450 9000
iMP-1500 1080 1350 1180 1475 4012-46TWG3A 258 4800*2180*2450 9635
iMP-1650 1200 1500 1320 1650 4012-46TAG2A 306 5000*2200*2580 10180
iMP-1875 1368 1710 1500 1875 4012-46TAG3A 333 5050*2200*2750 11580
iMP-2000 1460 1825 1600 2000 4016TAG1A 383 5800*2750*3300 12320
iMP-2200 1600 2000 1760 2200 4016TAG2A 434 6100*2900*3300 15600
iMP-2500 1800 2250 1980 2475 4016TRG3 473 6250*2900*3300

16000





300kva diesel generator set



300kva Diesel generator set



 300kva diesel generator set



300kva Diesel generator set



300kva diesel generator set








Our Services

300kva generator Warrantee: 1 year or 1200hours. During the waranty period, our factory would be responsible for problems caused by quality of our production or raw material, we will offer technical support or sending spare parts for replacement if need except the spare parts which required periodic maintenance, and the damages caused by incorrectman-made operation will also fall outside the clauses. After expiration, our company provides cost maintenance.   Further terms could be negotiable!
