Help Center2000mm M Shape Diamond Segment for Granite
US$ 0.5 - 1
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Kailin
Model Number:
GS-M AS4007
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Hot Sales Diamond Segment, Granite Segment, Cutting Segment All Over the WordUS$ 0.5 - 1MOQ: 1 Set -
Diamond Tools and Segment Granite ManufacturerUS$ 0.5 - 1MOQ: 1 Set
-
High Efficiency Block Type Diamond Cutting Segment for All Kinds of GraniteUS$ 0.5 - 1MOQ: 1 Set
-
Diamond Tools Marble Segment Granite Segment Marble Stone Cutting SegmentUS$ 0.5 - 1MOQ: 1 Set
-
China Hot Sales Diamond Segment for GraniteUS$ 0.5 - 1MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Kailin
Model Number
GS-M AS4007
Application
Other, Stone cutting
Package
Box
Number of Pieces
1
M shape Diamond segment:
1. Fast cutting;
2. Long life;
3. Granite cutting;
4. Manufacturer
About us
Nanan Kailin diamond tool factory is found in 1993. We are professional manufacturer. Our factory located in Shuitou town, which is a famous stone city.
Our products include:
1. Diamond segment for stone cutting;
2. Diamond saw blade:
- Diamond saw blade for granite cutting
- Diamond saw blade for marble cutting
- Diamond saw blade for marble and granite cutting
- Diamond saw blade for sandstone cutting
- Diamond saw blade for limestone cutting
- Diamond saw blade for quartz cutting
- Diamond saw blade for ceramic cutting
- Diamond saw blade for Jade cutting
- Diamond saw blade for microcrystal cutting
- Diamond saw blade for Mosaic cutting;
- Diamond saw blade for concrete cutting;
- Diamond saw blade for reinforced concrete cutting;
- Diamond saw blade for asphalt cutting;
- and so on..
3. Multi blade and Multi blade segment;
4. Diamond gang saw blade and gang saw blade segment;
5. Diamond core drill bit and core bit segment;
6. Diamond wire saw:
- Diamond wire saw for granite quarry;
- Diamond wire saw for marble quarry;
- Diamond wire saw for granite block squaring;
- Diamond wire saw for marble block squaring;
- Diamond wire saw for granite profiling;
- Diamond wire saw for marble profiling;
- Diamond wire saw for concrete cutting;
- Diamond wire saw for reinforced conctere cutting;
- Diamond multi wire saw
7. Diamond polishing tools and so on..
Diamond segment specification
| Diameter (mm) | Segment Dimension L*X*H (mm) | Core Thickness (mm) | Segment No. (pcs) |
| 250 | 40*3.0*10 | 1.8/2.0 | 18 |
| 300 | 40*3.2*12(15) | 1.8/2.2/2.4 | 21 |
| 350 | 40*3.2*12(15) | 1.8/2.2/2.4 | 24 |
| 400 | 40*3.4*12(15) | 2.2/2.6/2.8 | 28 |
| 450 | 40*3.8*12(15) | 2.5/2.8/3.3 | 32 |
| 500 | 40*4.2*12(15) | 2.8/3.0/3.2 | 36 |
| 550 | 40*4.2*12(15) | 3.0/3.5 | 40 |
| 600 | 40*4.6*12(15) | 3.0/3.6 | 42 |
| 700 | 40*5.0*12(15) | 3.6/4.0 | 46 |
| 800 | 40*6.0*12(15,20) | 4.5/5.0 | 46 |
| 900 | 24*6.6/6.2*15 | 5.O | 64 |
| 1000 | 24*7.4/6.8*15 | 5.O | 70 |
| 1100 | 24*7.4/6.8*15 | 5.5 | 74 |
| 1200 | 24*7.5/7.0*15(20) | 5.5 | 80 |
| 1300 | 24*8.0/7.4*15(20) | 6.O | 88 |
| 1400 | 24*9.0/8.4*15(20) | 6.5 | 96 |
| 1600 | 24*9.0/8.4*15(20) | 6.5 | 108 |
| 1800 | 24*10/9.0*15(20) | 7.O | 120 |
| 2000 | 24*10.6/9.8*15(20) | 8.O | 128 |
| 2200/2300 | 24*11.5/10.5*15(20) | 8.5 | 132/136 |
| 2500 | 24*11.8/10.8*15(20) | 9.5 | 140 |
| 3000 | 24*13.0/12*15(20) | 10 | 160 |
| 3500 | 24*13.5/12.5*20(30) | 11 | 180 |
Packing & Shipping
Packing: Plastic film, Paper box and wooden case;
Shipping: by Express, Air or Sea.
Photo of diamond segment
M shape Diamond segment Hand Tool Sets Product Diamond segment
2000mm M shape Diamond segment Hand Tool Sets Cutting material Granite
M shape Diamond segment for granite Hand Tool Sets Shape M
M shape Diamond segment Hand Tool Sets Inch 80"
