Specifications
Low cost,easy handle,1 year warranty.It's good for camping as emergency system.1, Battery-Can choose 12v 7.2 Ah/ 12Ah / 20Ah AGM battery if necessary
2, Solar panel-Can choose 10W or 20W or 40W solar panel with poly crystalline cell
3, DC output-(1.0A/12VDC*2)+(1.0A/1DC2V*2)
4, AC/DC Adaptor-19.0VDC / 2A, USB output-(1.0A/5VDC*1)+(0.5A/5VDC*2)
5, Car Charger output-4A/12VDC
6, Accessories-Optional
. External battery power cable
. AC/DC Adaptor
. USB Adaptor(mobile phone charging)
. LED light
Model |
SPS-off1210w |
SPS-off1220w |
SPS-off1240w |
AGM Battery(External) 12V |
7.2Ah |
12.0Ah |
20.0Ah |
Battery power(With ext.) 80% |
69.1W(138.2W) |
115.2W(230.4W) |
192.0W(384.0W) |
Solar panel(Expansion) 17.4V |
10Wp(10Wp) |
20Wp(10~20Wp) |
40Wp(20~40Wp) |
Output rated current |
10A/12V |
||
1,USB*3 |
2.0A/5VDC (1.0A/5V/1) + (1.0A/5V/2) |
||
2,DC jack(5.5*2.1)*4 |
4.0A/12VDC (2.0A/12V/2) + (2.0A/12V/2) |
||
3,Car socket*1 |
-------------- |
4.0A/12VDC 4.0A/12V/1 |
|
Main power switch*1 |
Yes |
||
Main power fuse*1 |
Yes |
||
External battery input socket |
Yes |
||
Solar panel input socket*1 |
Yes AC to DC power adapter Suitable |
||
AC to DC power adapter |
19VDC/1.0A |
19VDC/2.0A |
19VDC/3.0A |
Charge status |
Red→Failure Orange→Charging Green→Full power |
||
Power status |
Red→<=%33 Orange→>33% Green→>66% |
||
Initiative protection |
Main power switch buffer Main power fuse unit Battery high/low voltage Charge high voltage Output current limiting / reverse Output overload / short External battery buffer |
||
Passive protection |
Charge status Battery power Status Main power cut |
||
Loading time(With ext. bat.) |
DC LED bulb |
||
A,DC 1W LED bulb*4(Min) |
13.2hr(26.4hr) |
23.0hr(46.0hr) |
38.4hr(76.8hr) |
B,DC 3W LED bulb*4(Min) |
4.6hr(9.2hr) |
7.6hr(15.2hr) |
12.8hr(25.6hr) |
Power loading 30W(Min) |
2.3hr(4.6hr) |
3.8hr(7.6hr) |
6.4hr(12.8hr) |
Solar charging time |
Solar panel(With expansion solar panel) |
||
1,Without external battery |
7.0hr(3.5hr) |
5.8hr(3.8~2.9hr) |
4.8hr(3.2~2.4hr) |
2,With external battery |
--------(3.5hr) |
-------(3.8~2.9hr) |
-------(3.2~2.4hr) |
AC to DC power adapter charging time(Min) |
4.5hr |
3.8hr |
4.2hr |
Box material |
Plastic(ABS) |
||
Box dimension(REF) |
280 * 132 * 235 mm |
||
Box Weight(REF) |
3.8kg |
4.8kg |
6.0kg |
Loading capacity(1x20ft) |
720 sets |
480 sets |
320 sets |
Loading capacity(1x40ft) |
1440 sets |
960 sets |
640 sets |
