Specifications
Ceramic Fiber BlanketThickness:6-12.5-20-25-50
Size: 7200x610mm
Density:96-128-160kg/m3
Work temp:1050-1350C
Ceramic fiber blanket is made from high purity ceramic fiber by spun or blown process. It is asbestos free. No chemical binder is added. Double-size needling provides blanket with great tensile or handling strength for easy installation. Blankets are available in various classified temperature from 1100º C to 1430º C.
Characteristics:
1.Low thermal capacity, and excellent thermal property.
2.High temperature stability, resistance to thermal shock
3.Good tensile strength
4.Good high temperature performance
5.Excellent , and chemical corrosion resistance.
6.Light and good sound insulation.
Applications:
1. It is mainly applied in industrial furnaces, heating equipment and high temperature pipelines.
2.Thermal insulation material for electric power boiler, turbomachine and nuclear power plant.
3.Wall liners for high temperature reaction equipment and heating equipment in chemical industry.
4. Insulation materials for Roller kiln, tunnel kiln, shuttle kiln, and other kilns.
5.Heat insulation of furnace doors and head covers.
6. Fireproofing and heat insulation in high buildings.
7. High temperature filtering materials.
Tech Data.
Type |
Standard |
High pure |
High Alumina |
Zir-Alu |
Zirconium |
|
Chemical Composition(%) |
Al2O3 |
46 |
47-49 |
52-55 |
45-46 |
39-40 |
Al2O3+SiO2 |
98 |
99 |
99 |
-- |
88 |
|
ZrO2 |
-- |
-- |
-- |
5-7 |
15-17 |
|
Fe2O3 |
0.4 |
0.2 |
0.2 |
0.2 |
0.2 |
|
Na2O+ K2O |
0.3 |
0.2 |
0.2 |
0.2 |
0.2 |
|
CaO+MgO |
0.2 |
0.2 |
0.2 |
-- |
0.2 |
|
Classification Temp. (°C) |
1260 |
1260 |
1360 |
1360 |
1430 |
|
Working Temp. (°C) |
1050 |
1100 |
1200 |
1200 |
1350 |
|
|
Density (kg/m3)
|
64 |
64 |
96 |
96 |
128 |
|
160 |
160 |
160 |
160 |
160 |
||
|
Permanent Linear shrinkage(%) (After 24hours,128kg/m3) |
-3 |
-3 |
-3 |
-3 |
-3 |
|
(1000°C) |
(1100°C) |
(1250°C) |
(1100°C) |
(1350°C) |
||
|
Thermal Conductivity(W/m.k) (128kg/m3) |
0.09(400°C) |
0.09(400°C) |
0.12(600°C) |
0.13(600°C) |
0.16(800°C) |
|
0.16(800°C) |
0.16(800°C) |
0.20(1000°C) |
0.22(1000°C) |
0.20(1000°C) |
||
Tensile Strength(Mpa)(128kg/m3)) |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
|
Color |
Pure White |
Pure White |
Pure White |
Pure White |
Pure White |
|
Size (mm) |
14640x610x13; 14640x1220x13; 7200x610x25; 7320x610x25; 7200x1220x25; 3600x1220x50; 3600x610x50 |
|||||
