The Most Popular Best Sell Wood Laser Cutting Machine
US$ 1,500 - 8,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Made in Shanghai China Trade Assurance Carton Laser Cutting Machine Quality ChoiceUS$ 1,500 - 8,500MOQ: 1 Set -
New Coming Best Sell Sandal Laser Cutting MachineUS$ 1,500 - 8,500MOQ: 1 Set
-
China Supplier Special Best Laser Cutting MachineUS$ 1,500 - 8,500MOQ: 1 Set
-
China Supplier Manufacture High Quality Laser Machine for Cloth CuttingUS$ 1,500 - 8,500MOQ: 1 Set
-
Factory Hotsale Laser Cutting Foam MachineUS$ 1,500 - 8,500MOQ: 1 Set
Condition
New
Laser Type
CO2
Applicable Material
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Cutting Thickness
Depends on the material
Cutting Area
1300x2500mm
Cutting Speed
0-10000mm/s
CNC or Not
Yes
Cooling Mode
Water Cooling
Control Software
Ruida
Graphic Format Supported
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin
Shanghai, China
Brand Name
K&N
Model Number
ZL1325
Certification
CE, ISO, SGS, Other, CE, ISO, SGS, FDA
After-sales Service Provided
Engineers available to service machinery overseas
The Most Popular Best sell wood laser cutting machine
Product parameters of wood laser cutting machine
| Model | ZL6040 | ZL9060 | ZL1390 | ZL1610 | ZL1325 |
| Working Area | 600*400mm | 900*600mm | 1300*900mm | 1600*1000mm | 1300*2500mm |
| Laser Power | 50w/60w/80w/100w/130w/150w/180w | ||||
| Laser Type | Hermetic and Detached Co2 Laser tube | ||||
| Engraving Speed | 0-60000mm/s | ||||
| Cutting Speed | 0-10000mm/s | ||||
| Repeat Location Accuracy | +/-0.0125mm | ||||
| Min. shaping Character | Character: 2*2mm, Letter: 1*1mm | ||||
| Driving Mode | Stepper motor | ||||
| Position System | Red dot | ||||
| Interface | USB | ||||
| Voltage | AC220V/50HZ or 110V/60HZ or depend on customer | ||||
| Controlling System | CNC Prpfession Control System | ||||
| Support Graphics Mode | BMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,DST,PLT,DXF,etc. | ||||
| Cooling Mode | Circulation Water Cooling and Protection Pipe | ||||
| Cutting Platform | Professional Thickening Strip or Honeycomb Work Table | ||||
| Power Control Mode | Laser Energy Combining Movement Control System | ||||
| Operating Temperature | 0-45°C | ||||
| Operating Humidity | 5-95% | ||||
| Certification | CE,FDA,SGS | ||||
|
Machine Size ( mm ) |
1200*850*1070 | 1360*1030*1070 | 1760*1330*1070 | 2220*1580*1110 | 2000*3500*1100 |
| Net Weight | 180kg | 240kg | 360kg | 420kg | 900kg |
| Packing | Standard wooden box | ||||
| Guarantee Time | 3 Years | ||||
| Optional Item | Description | Applied Model |
| Motorized Up and Down System | Including Motorized Up and Down Table with Auto Focus. | ZL-6040/9060/1390/1610 |
| Rotary Fixture for Rotary Engraving | Rotary Engraving along the circle of cylindrical or column work pieces, usually applied in Advertisement and Craftwork. Need work together with Motorized Up and Down System. | ZL-6040/9060/1390/1610 |
| Vacuum Absorbing System | Specially design for garment and fabric industry, good for absorbing above uneven cloth / fabric / garment / leather, keep the thin material as planar/ even / flat surface always. Need with honeycomb work table. | ZL-6040/9060/1390/1610/1325 |
| Automatic Feeding and Rolling System | Suitable for engraving/cutting on very long work piece, such as one roller of cloth /fabric /leather /garment, the machine can be fixed with a selective rolling & automatic feeding system, which make the whole cloth processing steps finish one time. | ZL-6040/9060/1390/1610/1325 |
| Reci Laser Tube |
Lifetime: 10000hours Warranty Period: 10 months Power: 90W/ 100W/ 130W /150W Peak Power: 100W/ 130W/ 160W / 180W |
ZL-6040/9060/1390/1610/1325 |
| CCD Camera | Compensate automatically to pinpoint deformation of the fabric, it ensures the accuracy of cutting, shorten cutting path of human-based software design, saves time and increases efficiency for user. | ZL-1610 |
| Japan Import Servo Motor | Panasonic Brand, Fractionize drive, Low liberation, High speed &Small noise. |
Applied in all Models |
| Imported Ball Screw | With high speed and accuracy, it is smoothly for laser head to move speedily and laser beam to reflect with high accuracy. | ZL-1325 |
Applied materials
(1) Applicable materials: Non-metal materials such as acryl, wood planks, organic glass, plastic, light planks, bamboo ware, double color sheets, cloth, paper, leather, shells, ox horns, resin, animal grease, ABS boards, lamp shade, etc.
(2) Applicable Industries: For advertising, wood-working, plastic products, handicrafts, leather processing, paper cutting, etc.
Product pictures of wood laser cutting machine
