Full Automatic Plastic bag insert machine
Bag inserting machine
Packaging & Delivery
| Packaging Details: | wooden box |
| Delivery Detail: | 30 |
Applications:
For packaging various products such as food, electronic products, stationery, plastic products, hardware, screws, beverages and toys.
Applications:
The unit is suitable for various products such as frozen food, processed food products, agricultural products, electronic products, stationery, plastic products, hardware parts, toys, powders, and liquid foods
Features:
It can make bags with multiple lengths from a roll of flat or gushed film; places the bag into a carton and fold the top flaps of it over the edges
Different kinds of carton erectors can be linked
Adds a film-press device to make the observe bag which is especially suitable for food packaging
plastic bag insert machine,plastic bag inserter,8-10cartons.min
seal carton bag,protecting cattering and dusting
Specifications
plastic bag insert machine,, Bag inserting machine, plastic bag inserter,8-10cartons.min
seal carton bag,protecting cattering and dusting
Plastic bag insert machine are a great time and cost saving solution, that allows you to either fill directly into your box without other packaging, or to offer better protection for your precious product, by enveloping the product in a protect plastic bag layer.
Plastic bag insert machine suitable for different sectors, such as: food, electronic products, stationery, plastic products, beverages and so on.
From a tubular film roll, suction cups pick up the end of film and form the bag while the welding bar seals and cuts the bag.
This machine has an inverted insertion. The bag is inserted into the outside part of the box top flaps and by a blowing system the bag is pressed against the interior walls and bottom of the box. The box is ready to be filled.
Inserting Process
Technical features
Production (according format) - up to 10 boxes/min.
Electric power - 110V/220V/380V/400V, 50HZ/60HZ
Installed power - 2 Kw
Pneumatic installation - 6 bar
Film width - 460-840 mm
Film length equation Box: L+W+150mm = required film length
Machine dimensions
Length 2100 mm
Width 1490 mm
Height 1500 mm
Box dimensions
Length 300 - 400 mm
Width 200 - 300 mm
Height 150 - 250 mm
Plastic bag insert machine, Bag inserting machine, suitable for those sectors that have a high-need of hygiene, such as: frozen products, prepared meals, agricultural products, oil and so on.
From a tubular film roll, suction cups pick up the end of film and form the bag while the welding bar seals and cuts the bag. Finally, the bag is inserted into the box.
After the forming bag process, a press device equipped with a blowing system fully opens the bag. The box is ready to be filled.
Inserting Process
Technical features
Production (according format) - up to 10 boxes/min.
Electric power - 110V/220V/380V/400V, 50HZ/60HZ
Installed power - 2 Kw
Pneumatic installation - 6 bar
Film width - 460-840 mm
Film length equation - Box: L+W+140mm = required film length
Machine dimensions
Length 3170 mm
Width 2240 mm
Height 2300 mm
Box dimensions
Length 300 - 400 mm
Width 200 - 300 mm
Height 150 - 250 mm
