Double Happiness Table Tennis Cartoner From China

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Application:

Commodity

Packaging Type:

Case

Contact Supplier Request Quote Chat Now

Nantong Han Di Automation Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Commodity

Packaging Type Case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Pneumatic

Place of Origin Jiangsu, China

After-sales Service Provided Engineers available to service machinery overseas

Specifications

double happiness table tennis cartoner from china

Max speed	200 cartons per minute
Normal speed	180-200 cartons per minute
Model	TH260
Warranty period	1 year
Machine dimension	L4700W1495H1930
Rated voltage	380 V
Phase	3P+N+G
Frequency	60 HZ
Control Voltage	24 V
Main speed reducer	2.2 kW
Glue sprayer	6 kW
Control cabinet	0.8 kW
Total current	10 A
Vacuum degree	-0.08 Mpa
Compressed air consumption	15 L/min
Compressed air pressure	0.6 Mpa

TH260 series high speed cartoning machine

Automatic table tennis packing cartoner

It is widely used in the package field, such as pharmaceuticals, food, daily chemical and other industries, which can function independently and also can be joined to the whole packaging line.

It is mainly composed of the following parts:master driving section, metal gate infeed, carton-transferring unit, carton-suction unit, product-push unit, coding unit, carton-pressing unit, glue sprayer (carton flaps folding unit), discharge unit, electric control unit and pneumatic unit. Under coordinated work of the above parts, the product packing procedure is completed perfectly.

Specific operation principles are as follows:

Products flow onto the in-feeding conveyor from upstream machine, and were put to the transferring shoes by metal gate infeed unit.

When the metal gate infeed unit under the control of photoelectric switch detect that the products are ready,the carton-suction rod begins to suck carton,meanwhile carton-pull rod begins to pull the carton,and then the carton-folding rod unfold the carton,finally the carton is successfully put on the carton guide rail. The carton–suction device has a protection function -- no product entering, no carton suction .The product pusher unit boasts the protection function -- no pushing when there is product but no cartons.

The filled cartons will undergo flap-folding, coding, glue spraying and closing with the cooperation of the workbench closing unit. Later they will be tightened by the discharge conveyor and then transferred to the case packing platform.

Its visible speed is controlled by variable frequency and programmable control unit and the packing procedures are tracked by photo eyes. This machine boasts safety devices such as overloading protection, electricity leakage protection and failure alarm.

This user-friendly machine adopts world famous control elements with touch screen in both Chinese and English.

This compact equipment operates simply and reliably,boasting fast packaging speed,stable packaging quality,as well as smooth and beautiful packaging appearance.

Pre-Sale Services

Even before you purchase one of our products, we want to make sure you get the most out of the products you have chosen. That's why we offer these pre-sale services-to help you make the proper product selection in terms of size, specifications and application.

Sell Service

Listen to you carefully and offer you the best packing solution.

After Sale Service

We know that our customers need the assurance their packaging production operations can be depended upon! That's why we have a dedicated service department, consisting of expert factory trained equipment technicians to service the many different brands of systems we carry.

Han Di feels very strongly about the importance of supporting our customers and the product solutions we provide. Consequently we offer comprehensive maintenance options designed to prevent equipment issues before they become problems. As the old adage states, an ounce of prevention is worth a pound of cure!

Han Di provides monthly, quarterly, semi-annually and yearly maintenance agreements on a wide range of packaging equipment systems. This program has many benefits that will SAVE you TIME and MONEY!

Decreases Chance of Equipment Downtime
Increases Life of System
Maintains Optimal Equipment Efficiency
Increases the Safety of the Equipment
Increases System Reliability
Increase Production Levels

And you'll have the added assurance and peace of mind that your packaging operation will be operational when you need it most.

For your convenience, our service department will work according to your schedule. As an added benefit to our customers, we will send you a periodic letter to remind you when recommended preventative maintenance is due. The cost of the program is dependant upon number and type of equipment to be serviced.

Additionally our comprehensive preventative maintenance program is offered free of charge to our "Star Preferred Customer Group".

Some of the servicing maintenance solutions include:

Case erector

Box erector

Carton erector

Case packer

Box packer

Carton packer

Box filling machine

Box filling equipment

Box filling machinery

Case filling machine
