Specifications
Gold supplier of cartoner from ChinaGold supplier of cartoner from China
Automatic high speed cartoning machine
TH260 series full-automatic cartoner is widely used in the package field, such as pharmaceuticals, food, daily chemical and so on. It can function independently, or can be joined to the whole packing line.
It is mainly composed of the following parts:master driving unit, product-transferring unit, product-suction unit, carton-transferring unit, carton-suction unit, product-push unit, coding unit, carton-pressing unit, glue sprayer (carton flap folding unit), discharge unit, electric control unit and pneumatic unit. Under coordinated work of the above parts, the product packing procedure is completed perfectly.
Specific operation principles are as follows:
Products flow onto the feeding-in belt from upstream machine, and were put to transferring shoes by product suction unit.
When the suction cups under the control of photoelectrical switch detect that the products are ready,the carton-suction rod begins to suck carton,meanwhile carton-pull rod begins to pull the carton,and then the carton-unfolding rod unfolds the carton,finally the carton is successfully put on the carton guide rail. The carton –suction device has a protection function -- no product entering, no carton suction.The product pusher unit boasts the protection function of -no push when there is product without cartons.
The products which enter cartons will undergo flap folding, coding, glue spraying and closing with the cooperation of workbench closing unit. The cartons filled with products will be tightened by the discharge conveyor and then transferred to the case packing platform.
This machine’s speed is controlled by variable frequency and programmable control unit. The visible packing speed and the packing procedures are tracked by photo eyes. This machine boasts safety devices such as overloading protection, electricity leakage protection, and failure alarm.
This user-friendly machine adopts world famous control elements with touch screen in both Chinese and English.
This compact equipment operats simply and reliably,boasting fast packaging speed,stable packaging quality,as well as smooth and beautiful packaging appearance.
