Specifications
LeadingTouch Touch Bezel is touch solution for Monitor, ATM, Gaming Mechine, Kiosks, POS, and so on.LeadingTouch 15" Surface Acoustic Wave SAW Touch Frame TM-1559
TouchBezel is Leadingtouch patent solution for easy integration to a touch display. Touchscreen is sealed inside top quality metal or plastic frame with customer assembly holes around, which is easy to assembly to the rear cover of customer’s display system by some screws. With Leadingtouch touchbezel, you may no need to custom another front cover for touchscreen integration and all integration process is as easy as assembly a front cover to your system’s rear cover. Now we have M type, L type and P type touchbezel for your choice to convenient your assembly.
Leadingtouch SAW touchbezel, integrated with Leadingtouch superior SAW touchscreen, is drift-free quick response and of high resolution. Its dustproof, waterproof, anti-vandal performances ensure it works well in harsh environment where dust and liquid is prevalent. All touchbezels combine with Leadingtouch Comb controller card, bring flexibility and convenience for you to use either USB or RS232 interface.
Size | |
General Size |
15″ to 24″ |
Custom Size |
8.4″ to 26″ |
Fit in with |
Panel display device |
Performance | |
Resolution(Interpolation) |
4096*4096 |
Linearity Error |
<±1% |
Response Speed |
<10ms |
Mechanical | |
Construction |
Sensors are sealed inside frames |
Frame Material |
Metal / Plastic |
Input Method |
Finger or gloved hand (rubber ,cloth or leather) |
Touch Times |
7,000,000 |
Touch Activation Force |
<85g |
Vandal-proof |
No break by 1-pound steel ball dropping from 130 cm high |
Waterproof |
No defect by applying water on active area |
Dustproof |
With frames sealed by dustproof strips to prevent dust from accumulating on sensors |
Surface Durability |
Surface durability is that of glass, Mohs' hardness rating of 7 |
Optical | |
Light Transmission |
90%(Meet ASTM D1003) |
Gloss |
Antiglare surface (curved or flat): 95 ± 15 gloss units or 65 ± 15 gloss units |
per ASTM D2457 using a 60-degree gloss meter | |
Environmental | |
Temperature |
Operating Range: -20°C ~ 70°C |
Storage Range: -40°C ~ 85°C | |
Relative Humidity |
Operating Range: 0%~90% RH (no dew falls) |
Storage Range: 0% to 95% RH (no dew falls) | |
Altitude |
Up to 5,000m |
Life Time |
At least 10-years |
Electrical | |
Operation Voltage |
Typical +DC 5V, +4.75V to +5.25V |
Power Supply |
USB or PS/2 interface |
Interface |
Full Duplex USB 2.0 (Full Speed) Plug and play compatible |
Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity | |
Electrostatic Protection |
15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4) |
Touchpoint Density |
>100,000 touchpoints/in² (15,500 touchpoints/cm²) |
Agency Approvals |
CE, FCC, Rohs |
Operating System | |
Operation System Linux/ Dos / Windows ME/95/98 / NT4.0/XP/2000/Mac OS | |
Reliability | |
MTBF |
Greater than 1,543,000 hours per MIL-HDBK-217-F2 |
Thermal Cycling |
Ambient (0.5 hr) to 65°C / 90%RH (0.5 hr), 12 thermal cycles, 2°C/Minute |
