Specifications
1, Dual rs232 and USB saw controller2, Support ELO driver, size,connect,all dimension same elo controller
LeadingTouch 6020S Surface Acoustic Wave SAW Touchscreen Serial RS232 Controller , the newest controller supplied by Leadingtouch, is designed for Surface Acoustic Wave touchscreen, can support full series of SAW touch produc.
6020S controller providing Serial(RS-232) interface with many superior advantages such as stable performance and fast reaction.
Model |
6020S |
Construction |
Four-layer surface-mount design with internal ground plane for EMI suppression. |
Dimensions |
Total width: 2.46 inches (62.5 mm), including connectors |
Total length: 3.30 inches (85 mm) | |
Total height: 0.47 inches (11.8 mm) | |
Supply Voltage |
+5 VDC, nominal (+4.75 to +5.25V DC), and Current 85mA typical, 105mA maximum at +5 VDC. |
Typical power dissipation is 425mW at 5V. Minimum power-supply 200 mA., Inrush current up to 600mA for 50mS. | |
Serial Interface |
EIA 232E (Serial RS-232), DCE configuration. 9600 Baud Rate, 8 Data Bits, 1 Stop Bit, No Parity, Full Duplex |
Operating Modes |
Leadingtouch protocol |
Customer specific protocol | |
Initial/ Stream/ Untouch Modes | |
Touch Resolution |
4096x4096, size independent |
Conversion Time |
Approximately 10 ms per coordinate set |
Reliability |
MTBF greater than 1,543,000 hours per MIL-HDBK-217-F2 |
Temperature |
Operating: 0°C to 65°C; Storage: -25°C to 85°C |
Humidity |
Operating: 10% to 90% RH, noncondensing; Storage: 10% to 90% RH, noncondensing |
Operating Altitude |
10,000 feet |
Shock and Vibration |
With Leadingtouch standard container, meet International Safe Transit Association project 2A test procedure. |
ESD: |
Per EN 6100-4-2 1995. Level 4, Contact Discharge - 8kV ; Air Discharge - 15kV positive and negative polarity |
Flammability |
94V0 |
LED Indicators |
The 6020E controller has one LED status indicators. When 6020E controller initially connects to host, the LED will be constantly on. When touchscreen connects to 6020E, the LED will snuff out after 3 seconds and be constantly on during touch. |
Agency Approvals |
The touch system including 6020E controller, touchscreen and connection cable has certified with FCC Part 15. |
