Help CenterEasily Operation Spiral Piling Machine for Solar Ground Mount System
Related Products
-
Ground Screw Electric-Driver Machine for Fence WBQ HD-03US$ 1,400 - 2,000MOQ: 1 Unit -
Ground Screw Electric-Driver Machine for Solar Power SystemUS$ 1,000 - 2,000MOQ: 1 Set
-
SWDL150 Spiral Piling Machine for Solar SystemUS$ 10,000 - 60,000MOQ: 1 Piece
-
SWDL150 Spiral Piling Machine for Solar System, ConstructionsUS$ 10,000 - 60,000MOQ: 1 Piece
-
SWDL150 Spiral Piling Machine for Solar System, Constructions, IndustriesUS$ 10,000 - 60,000MOQ: 1 Piece
Specifications
1.Easily operation2.Application for digging&drilling
3.Use for the solar power system project
1. Main Data
| Spiral Pliling Machine | |||
| Main Data | Unit | SWDL150 | SWDL 600 |
| Opeation Parameter | |||
| Pile Diameter | mm | 76 | 76-90 |
| Pile Depth | mm | 1800 | 3000 |
| Chassis | |||
| Track base | mm | 1430 | 2240 |
| Gauge | mm | 1150 | 1680 |
| Ground width | mm | 250 | 400 |
| Ground clearance | mm | 280 | 340 |
| Blade length | mm | 1400 | 2080 |
| Engine | |||
| Model | YANMAR-3TNV82A | V3300-DI | |
| Displacement | L | 1.331 | 3.3 |
| Power/Speed | KW/RPM | 16/2200 | 54.9/2600 |
| Fuel tank | L | 2 | 140 |
| Feed | |||
| Length of drillring | mm | 3400 | 4800 |
| Feed length | mm | 2000 | 3500 |
| Feed speed | m/min | 2 | 3 |
| Travelling | |||
| Travel speed | KM/H | 4.7/2.6 | 4.5/3.1 |
| Traction force, max | KN | 19 | 55 |
| Hill climbing ability | 20 | 20 | |
| Rotary | |||
| Roatry speed, max | RPM | 40 | 40 |
| Rotary torque,max | N.M | 3000 | 6000 |
| Diamension | |||
| Gross weight | KG | 3000 | 7800 |
| Diamension(L*W*H) | mm | 5650*1400*2600 | 8437*2190*3150 |
Technical Features:
1, The machine is base on the excavator system, which can complete digging and drilling work by different work devices. Turntable can fully 360°swing, and whole machine is flexibly.
2, Easy and flexible operation: All actions including travel, dozer, turntable swing, work devices, pile rotation and feed etc. are all controlled by advanced hydraulic pilot valve. Work operation is in the cabin which can reduce operating force and operator’s load, and advance the control stability.
3, Drill frame angle display is fit in the cab, which make operation clearly.
4, The machine is supplying special clamping fixtures for piles, easy assembling and disassembling, high efficiency.
5, The machine is supplying pile guiding device which can ensure the verticality of pile drill.
6, Safety and reliable key parts: YANMAR-3TNV82A Engine from Japan, Hydraulic system main pump, Main valve, swing motor, travel motor are all from KYB Janpa.
