Help CenterXCMG GR300 300HP Motor Grader
Related Products
-
XCMG Engineering Machinery Vehicles GR300 Grader , Motor Grader PriceUS$ 1 - 2MOQ: 1 Set -
XCMG Engineering Machinery Vehicles GR260 Motor Grader Quality ChoiceUS$ 1 - 2MOQ: 1 Set
-
SDLG New Generation 190HP Motor Grader G9190 (HP165, HP180, HP190, HP200, HP200 for Choice)US$ 70,000 - 80,000MOQ: 1 Set
-
Chinese Famous Brand SDLG190HP Motor Grader G9190 for SaleUS$ 70,000 - 80,000MOQ: 1 Set
-
SDLG Best Selling190HP Motor Grader G9190 for SaleUS$ 70,000 - 80,000MOQ: 1 Set
1.Famous brand (SDLG) in China,high quality at favorable price .These products has occupy much market all over the world.
2.It is equipped with the Weichai DEUTZ turbocharged engine
3.Bucket is made of protruding type cutting board.
PRODUCT PARAMETERS
Basic specification | |
Engine model |
QSL9 |
Rated power/speed |
224kW/2100rpm |
Dimension(LxWxH) |
10500×3100×3550mm |
Operating weight(Standard) |
26000kg |
Performance specification | |
Travelling speed ,forward |
5,8,11,19,23,40 km/h |
Travelling speed ,reverse |
5,11,23 km/h |
Tractive force(f=0.75) |
140KN |
Max. gradeability |
30% |
Tire inflation pressure |
350 kPa |
Working hydraulic pressure |
16 MPa |
Transmission pressure |
1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels |
±50° |
Max. lean angle of front wheels |
±17° |
Max. oscillation angle of front axle |
±15° |
Max. oscillation angle of balance box |
15 |
Frame articulation angle |
±27° |
Min. turning radius using articulation |
8.0m |
Biade | |
Maximum lift above ground |
450mm |
Maximum depth of cutting |
500mm |
Maximum blade position angle |
90° |
Blade cutting angle |
28°—70° |
Circle reversing rotation |
360° |
Moldboard width X height |
4920×787mm |
