High Quality 2 Cylinder Water Cooled Diesel Engine
US$ 1 - 50
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
pengsheng
Model Number:
DD152F/P
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2 Cylinder Water Cooled Diesel Engine Made in ChinaUS$ 1 - 50MOQ: 1 Unit -
Series Diesel Engine for Marine Use With Gearbox Made in ChinaUS$ 1 - 1,000MOQ: 1 Unit
-
Marine Water-cooled Diesel Engine Made in ChinaUS$ 1 - 1,000MOQ: 1 Unit
-
High Quality Water-cooled Diesel Engine Made in ChinaUS$ 1 - 1,000MOQ: 1 Unit
-
Water-cooled Diesel Engine Made in ChinaUS$ 1 - 1,000MOQ: 1 Unit
Place of Origin
Shandong, China
Brand Name
pengsheng
Model Number
DD152F/P
Output Type
AC Single Phase
Main Technical Parameter of high quality 2 cylinder water cooled diesel engine
| DD152F/P | DD154FP | DD156F/P | |
| Engine Type | Single cylinder,4 strokes, side valve,air cooling | OHV25°slant,single cylinder,4 strokes,air cooling | OHV25°slant,single cylinder,4 strokes,air cooling |
| Displacement(cc) | 97cc | 90cc | 98cc |
| Bore×Stroke(mm) | 52mm×46mm | 54mm×40mm | 56mm×40mm |
| Rated Power(KW) | 1.1kW/3600rpm | 1.5kW/3600rpm | 1.7kW/3600rpm |
| Max Torque N.m(r/m) | 3.2 N.m/3000rpm | 4.5N.m/3000rpm | 5.0N.m/3000rpm |
| Idle Speed | 1800±150r/min | 1700±150r/min | 1700±150r/min |
| Compression Ratio | 5.6/1 | 10/1 | 8.5/1 |
| Output Rotate System | CCW(from output shaft) | CCW(from output shaft) | CCW(from output shaft) |
| Valve Clearance | Suction Valve0.10±0.02;Exhaust Valve0.15±0.02 | Suction Valve0.10±0.02;Exhaust Valve0.15±0.02 | Suction Valve0.10±0.02;Exhaust Valve0.15±0.02 |
| Ignition System | Transistor Magneto | Transistor Magneto | Transistor Magneto |
| Starting System | Recoil Start | Recoil Start | Recoil Start |
| Carburetor | Horizontal Saucer Valve | Horizontal Saucer Valve | Horizontal Saucer Valve |
| LubricartionSystem | SplashType | SplashType | Splash Type |
| Governor System | Centrifugation Mechanical | Centrifugation Mechanical | Centrifugation Mechanical |
| Air Cleaner | Semi-dry Filter | Single Filter | Single Filter |
| Lube Oil Comsumption (KW)(r/min) | ≤6.5g/kW .h | ≤6.5g/kW .h | ≤6.5g/kW .h |
| Fuel Consumption(g/kw.h) | ≤435g/kW .h | ≤450g/kW .h | ≤435g/kW .h |
| Engine Oil Type | SAE15W-40/<0℃:SAE5W-30 | SAE15W-40/<0℃:SAE5W-30 | SAE15W-40/<0℃:SAE5W-30 |
| Fuel Type | 93# or Higher-grade Unleaded Petrol | 93# or Higher-grade Unleaded Petrol | 93# or Higher-grade Unleaded Petrol |
| Engine Oil Capacity(L) | 0.4L | 0.4L | 0.4L |
| Fuel Tank Capacity(L) | 1.4L | 2.0L | 2.0L |
| NW(kg) | 9kg | 10kg | 10kg |
| GW(kg) | 10kg | 11kg | 11kg |
| Dimension(L×W×H)(mm) | 280×270×345 | 310×260×305 | 310×260×305 |
| Packing(mm) | 295×285×365 | 340×300×375 | 340×300×375 |
| Loading Quantity | 20':912sets 40':1920sets 40HQ:2240sets | 20':714sets 40':1470sets 40HQ:1715sets | 20':714sets 40':1470sets 40HQ:1715sets |
