Air-cooled Single Cylinder Diesel Engine 170/178/186188/
US$ 1 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
pengsheng
Model Number:
S170F(E)
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Series Diesel Engine for Marine Use With GearboxUS$ 1 - 1,000MOQ: 1 Unit -
Best Sale 2 Cylinder Water Cooled Diesel EngineUS$ 1 - 50MOQ: 1 Unit
-
China Supplier of Water-cooled Diesel EngineUS$ 1 - 1,000MOQ: 1 Unit
-
High Quality 2 Cylinder Water Cooled Diesel EngineUS$ 1 - 50MOQ: 1 Unit
-
2 Cylinder Water Cooled Diesel Engine Made in ChinaUS$ 1 - 50MOQ: 1 Unit
Place of Origin
Shandong, China
Brand Name
pengsheng
Model Number
S170F(E)
Specifications of Air-cooled Single Cylinder Diesel Engine 170/178/186188/
1.stable power
2.long service life
3.good power performance
4.wide application
5.portable & easy start
| Model | S170F(E) | S178F(E) | S178FA(E) | S186F(E) | S186FA(E) |
| Type | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled |
| Bore*stroke (mm) | 70*55 | 78*62 | 78*64 | 86*70 | 88*75 |
| Dislacement (L) | 0.211 | 0.296 | 0.305 | 0.406 | 0.456 |
| Combustion system | direct injection | direct injection | direct injection | direct injection | direct injection |
| Rated output KW (HP) / rpm | 2.5 3.4/3000 2.98(4.0)/ 3600 | 3.8 (5.1) / 3000 4.4 (5.9) / 3600 | 3.8 (5.1) / 3000 4.4 (5.9) / 3600 | 5.7 (7.75) / 3000 6.6 (8.85) / 3600 | 6.08 (8.15) / 3000 7.3 (9.78) / 3600 |
| Max output KW (HP) / rpm | 2.8 3.8/3000 3.36 (4.5) / 3600 | 4.0 (5.36) / 3000 4.9 (6.6) / 3600 | 4.0(5.36) /3000 4.9(6.6) / 3600 | 6.3 (8.57)/3000 7.34 (9.85) / 3600 | 6.83 (9.15) / 3000 8.2 (11.0) / 3600 |
| Direction of rotation | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft |
| Fuel | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) |
| Fuel tank capacity (L) | 2.5 | 3.5 | 3.5 | 5.5 | 5.5 |
| Lubricating oil capacity (L) | 0.75 | 1.1 | 1.1 | 1.65 | 1.65 |
| Lubricating system | Pressure splashed | Pressure splashed | Pressure splashed | Pressure splashed | Pressure splashed |
| Starting system | Manual / Electric start | Manual / Electric start | Manual / Electric start | Manual / Electric start | Manual / Electric start |
| Packing size (L*W*H) mm | 415*385*470 | 485*475*525 | 485*475*525 | 500*470*555 | 500*470*555 |
| Net weight (KG) | 26 | 35 | 35 | 48 | 48 |
| Model | S188FB(E) | S178FS(E) | S186FS(E) |
| Type | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled | Single cylinder, vertical, 4-stroke, air cooled |
| Bore*stroke (mm) | 88*75 | 78*62 | 86*70 |
| Dislacement (L) | 0.456 | 0.296 | 0.406 |
| Combustion system | direct injection | direct injection | direct injection |
| Rated output KW (HP) / rpm | 6.08 (8.15) / 3000 7.3 (9.78) / 3600 | 3.8 (5.1) / 1500 4.4 (5.9) / 1800 | 5.7 (7.75) / 1500 6.6 (8.85) / 1800 |
| Max output KW (HP) / rpm | 6.83 (9.15) / 3000 8.2 (11.0) / 3600 | 4.0 (5.36) / 1500 4.9 (6.6) / 1800 | 6.3 (8.57) / 1500 7.34 (9.85) / 1800 |
| Direction of rotation | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft | Counterclockwise, facing PTOshaft |
| Fuel | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) | 0# (Summer) / -10# (Winter) |
| Fuel tank capacity (L) | 5.5 | 3.5 | 5.5 |
| Lubricating oil capacity (L) | 1.65 | 1.1 | 1.65 |
| Lubricating system | Pressure splashed | Pressure splashed | Pressure splashed |
| Starting system | Manual / Electric start | Manual / Electric start | Manual / Electric start |
| Packing size (L*W*H) mm | 500*470*555 | 485*475*525 | 500*470*555 |
| Net weight (KG) | 49 | 35 | 48 |
Applications
A simple, compact, and lightweight engine for a wide array of applications.Great for agricultural, rental, construction site, and home use.
