Material:Glass fiber paper, chemical fiber paper
Structure:end and bottom end caps, material is stainless steel and plastic
inner tube, material is stainless steel
filter medium, material is stainless steel mesh
Structure and material | |
Part name | material |
End and bottom caps | plastic , stainless steel |
Inner tube | Stainless steel |
Filter medium | Stainless steel mesh |
Application: strainer candle Apply in metallurgical, petrochemical, machinery manufacturing, paper making, textile, food and medicine, life, and environmental protection, oil, water filtration, involving all industries:
Crude oil, fuel oil, petrol, kerosene, diesel oil filter, etc
The hydraulic oil, lubricating oil, oil, gear oil filter .etc
Raw water, sewage , plain water ,reclaimed water filtration .etc
Use scope | strainer candle mainly used to metallurgy , chemical industry , machinofacture , papermaking , spinning , food medicine , livelihood , environmental protection etc. which involved oil , water filter industry |
Raw oil , fuel oil , diesel oil , kerosene , gasoline ,etc . filtering | |
Lubricating oil , hydraulic oil ,machine oil , gear oil etc. filtering | |
Raw water , sewage , plain water , reclaimed etc. clear filtering. |
Ferture:
Pressure: ≤1.6Mpa
Flow rate : 20-60L/min
strainer candle's working medium: hydraulic oil and lubricating oil
Loss press: <0.1Mpa
Filter material: stainless steel
Size: φ30*223~φ30*745
.the high intensity, long service life, corrosion resistance, temperature range, without material from
.big filter area, big flow, porosity, permeability, high carrying capacity, with strong sex (can be repeated cleaning)
. with size, Z series (type filter) filtering area for Y series (cylindrical) filtering area of 2.5-4 times, prolong the cartridge replacement cycles
. installation ,removal and clean easily
Ferture | |
Pressure | Less than 1.6MPa |
Flow rate | 20-60L/min |
Working medium | Hydraulic oil and lubricating oil |
Loss pressure | Less than 0.1MPa |
Filter material | Stainless steel |
Size | φ30*223~φ30*745 |
Feature | |
Using life | Long , can be clean and use again |
Temperature | Big range |
Accept dirt | Strong ability |
Area and flow | Big |
Advantages | Easy install , use economy |
Name | Model | Connection type | Flow capacity (L/min) | Micron rating (um) | Nominal pressure(MPa) | Pressure loss(MPa) | Size (mm) | ||
Initial | Max | D | L | ||||||
strainer candle element | BYLX-30×223 | M26×1.5 | 20 | 20 25 30 40 80 | 1.0 | No more than 0.1 | 0.35 | 30 | 223 |
BYLX-30×400 | 35 | 30 | 400 | ||||||
BYLX-30×440 | 40 | 30 | 440 | ||||||
BYLX-30×723 | 60 | 30 | 723 | ||||||
BYLX-30×245 | φ26 | 20 | 30 | 245 | |||||
If you are interested in our strainer candle , pls sent the following questions to us , we will calculate the best to you with the specifications :
- size : diameter , length
- micron rating
- quantity
...
