Production Description:
1. High-reliability and wide range application:
Such as water tank, oil tank, Lampshade, military box, urea box, conduit shaft, roadblock, floating body, automotive parts, kayak, feeding system, water channel, septic tank, etc.
2. Effective energy saving and environment protection:
Two arms move the molds back and forth between heating chamber and cooling station. Fast heating and cooling. The mold can be easy changed frequently. Flexible and adaptable to variety of products at the same time.
3. Fully automatic PLC control system:
Easy operation also save both time and effort.
4. Breakdown self check and real-time monitoring the temperature of heating chamber.
5. Patent technology, precision manufacturing to ensure the production efficient and stable.
6. Perfect after-sales service system;
| Model no. | L(m) | W(m) | W1 | H(m) | Inside of Oven | Operation Station |
| FD2-1600 | 8.5 | / | 3.9 | 2.8 | φ1.6x1.6 | without |
| FD2-2100 | 11.0 | / | 4.9 | 3.5 | φ2.1x2.1 | without |
| FD2-2600 | 13.0 | 8.1 | 5.6 | 4.0 | φ2.6x2.6 | Moving |
| FD2-3100 | 14.7 | 9.3 | 6.1 | 4.5 | φ3.1x3.1 | Moving |
| FD2-3600 | 16.3 | 10.0 | 6.8 | 5.0 | φ3.6x3.6 | Moving |
| FD2-4100 | 18.0 | 11.0 | 7.5 | 5.5 | φ4.1x4.1 | Moving |
| FD2-4600 | 20.0 | 11.5 | 8.0 | 6.0 | φ4.6x4.6 | Moving |
| FD2-5100 | 22.0 | 12.0 | 8.7 | 6.5 | φ5.1x5.1 | Moving |
| FD2-5600 | 24.0 | 12.5 | 9.2 | 7.0 | φ5.6x5.6 | Moving |
| FD2-6100 | 26.0 | 13.0 | 10.0 | 7.5 | φ6.1x6.1 | Moving |
Yantai Fangda Rotational Molding Co., Ltd.,established in 2002, occupying an area of 30,000 square meters, is the key Hi-Tech Enterprise of Shandong Province, and is certified by ISO 9001. Now, our company has been the largest R&D Center and Production Base of Rotational Molding Equipments in China.
For many years, we are committed to High Technology and Technical Innovation. And we benefit a lot from the consistent Investment on R&D: the Municipal High-End Rotomolding Euquipment Engineering and Technology Research Center has been established, and 12 inventions of our company already obtained the National Patent. Our company independently researched and developed the 4-Arm 6-Station Rotomolding Machine and the Shuttle Machine which have reached the International Advanced Level.
Our main products are: Rotomolding Equipments, Moulds, Spinning Equipments, etc, and till now, our products are widely used on domestic market and also exported to more than 10 countries and regions such as Australia, Russia and Indonesia. With high-quality products and complete after-service, we already win high praise from clients home and abroad.
We sincerely hope that we can cooperate together and grow together.
Welcome to your visiting!
