Help CenterMULTIFUNCTION AUTOMATIC WELDING MACHINE (TIG+MIG+SAW)
Related Products
-
Piping Spool Automatic Welding Machine(TIG+MIG+SAW)NegotiableMOQ: 1 Set -
New Advanced Automatic Pipe Welding Machine(TIG+MIG+SAW)NegotiableMOQ: 1 Set
-
Piping Spool Automatic Welding Machine With Two Welding Torches(TIG+MIG)NegotiableMOQ: 1 Set
-
New High Quality Muti-function Pipe Automatic Welding Machine With Three Welding Torches (TIG+MIG+SAW)NegotiableMOQ: 1 Set
-
AUTOMATIC WELDING MACHINE FOR PIPE FABRICATION;PIPE WELDING MACHINE;AUTOMATIC PIPE WELDING MACHINE;(SAW)NegotiableMOQ: 1 Set
Specifications
Multifunction welding machine for automatic pipe spool root pass, fill in & final welding with high qualified of NDT, X RAYMultifunction Automatic Pipe Welding Machine (TIG+MIG+SAW)
Automatic Pipe Welding Machine/ Pipe Welding Equipment
Model No.: PPAWM-16Aa, PPAWM-24Aa, PPAWM-32Aa, PPAWM-40Aa, PPAWM-48Aa
Performance features
On-line Performance: Excellent (Designed completely as per the on line equipment of the production line)
Application: Backing welding or welding the pipes or the cover of the aluminum alloy pipe which need higher quality.
Welding Capacity: High (250-500 Dia-inch/day)
Operability: Good (applicable and easy to operate even if you are a new user within a short period of time).
Surface finishing: Excellent (the welding gun will always be positioned in the optimum position)
Welding compliance rate: 98% min (without re-working for the skilled operator).
Driving Reliability: Good (driven by frictional force, however, it is required to set essential balance weight to offset large bending moment caused by elbows for large diameter pipe, or providing a chain tensioner to improve the reliability of the driving).
Technical Parameters
Pipe diameter applicable: DN50-400 (OD60~426); DN50~600(OD60~610); DN200-800(OD219-813);
DN400-1000 (OD426-1016); DN 600-1200 (OD 610-1219)
Pipe wall thickness applicable: 3~60mm
Materials applicable: Carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
Welding line applicable: Various butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc (a fake pipe transition connection shall be applied if necessary).
Driving System: Driven by rubber rotator and reducer Clamping system: Clamping by Boom with Press Roller;
Bracket System: Separate type of trolley matching for welding machine, which may height & length adjustable along the track according to the length of the piping
Counterweight System: No Counterweight
Speed~regulation Mode: VF stepless speed control system
Adjustment Mode: With electric cross regulator
Oscillating system: A product of our patented technology, driven by step motor.
Control system: A product of our patented technology, PLC control with touch screen.
Welding procedure: TIG/MIG/FCAW/SAW (applicable for pipe root run, fill in & final welding)
Welding power: LINCOLN, MILLER OR domestic brand (As per customer's demand)
Technicas Specification Table:
| Technical Description: | Standard Type |
| Welding Capacity: | 250-500 Dia-Inch/day (4 times higher than the manual welding) |
| Pipe Diameter Applicable: | DN50-400/DN50~600/DN200-800mm/DN400-1000/DN600-1200mm |
| Pipe Wall Thickness Applicable: | 3~60mm |
| Materials Applicable: | Carbon Steel, Alloy Steel, Stainless Steel and Cryogenic Steel |
| Welding procedure: | TIG/MIG/FCAW/SAW (applicable for pipe root pass, fill in & final welding) |
| Welding Qualified Pass Ratio: | exceed 99% by NDT or X-Ray. |
Photos Show:
Welcome you to get more informations by email or website: thanks a lot !
