Help Center171LB.CR,175LB.CR RAIL SPLICE BAR
US$ 5 - 30
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Type:
Other, RAIL SPLICE BAR
Material:
AREMA GRADE/STEEL GRADE 55#
Dimensions (L x W x H) (mm):
ACCORDING TO STANDARDS AND CUSTOMERS' REQUIREMENTS
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other, RAIL SPLICE BAR
Material
AREMA GRADE/STEEL GRADE 55#
Dimensions (L x W x H) (mm)
ACCORDING TO STANDARDS AND CUSTOMERS' REQUIREMENTS
Place of Origin
Henan, China
Brand Name
LT
Model Number
171LB.CR RAIL SPLICE BAR,175LB.CR RAIL SPLICE BAR
Specifications
AREMA RAIL SPLICE BAR STANDARD:AREMA 2007.MODEL:171LB.CR RAIL SPLICE BAR,175LB.CR RAIL SPLICE BAR.
We specialize in producing all kinds of railway products such as rail splice bars,fish bolts,gauge aprons,screw spikes,elastic clips,rubber tie plates,gauge ties,etc.
We are always keeping providing better products and higher-class service to satisfy our customers.
Rail splice bars are used to joint or connect two rails together, and rail splice bars are also called as rail fishplates or rail joint bar.
Rail splice bars we can provided as below:
AREMA standard RAIL SPLICE BAR:175LB.CR RAIL SPLICE BAR,105LB.CR RAIL SPLICE BAR,135LB.CR RAIL SPLICE BAR,171LB.CR RAIL SPLICE BAR.
| CHINESE STANDARD RAIL SPLICE BAR | |||||||||
| SIZE | STANDARD | MATERIAL | |||||||
| 43KG | TB/T2345-2008 | B7 | |||||||
| 50KG | |||||||||
| 60KG | |||||||||
| 75KG | |||||||||
| BS STANDARD RAIL SPLICE BAR | |||||||||
| SIZE | STANDARD | MATERAIL | |||||||
| BS75R | BS47-1 | EUROPEAN GRADE 700 | |||||||
| BS80A | |||||||||
| BS90A | |||||||||
| BS100A | |||||||||
| BS113A | |||||||||
| RAIL SPLICE BAR FOR JIS E STANDARD RAIL | |||||||||
| RAIL SIZE | RAIL SPLICE BAR STANDARD | MATERIAL | |||||||
| 37A | JIS E 1102-2001 | SS490,S20C | |||||||
| 50N | |||||||||
| CR73 | |||||||||
| CR100 | |||||||||
| RAIL SPLICE BAR FOR AREMA 2007 STANDARD STEEL RAIL | |||||||||
| T-RAIL | STANDARD | MATERIAL | HOLE DIAMETER | ||||||
| 100LB.ASCE | AREMA 2007 | AREMA GRADE/STEEL GRADE 55# | 1.1875" | ||||||
| 115RE | 1.1876" | ||||||||
| 132RE | 1.13125" | ||||||||
| 136RE | 1.13126" | ||||||||
| RAIL SPLICE BAR FOR CRANE RAIL | |||||||||
| 104LB.CR | AREMA 2007 | AREMA GRADE/STEEL GRADE 55# | 1.0625" | ||||||
| 105LB.CR | 1.3125" | ||||||||
| 135LB.CR | 1.1875" | ||||||||
| 171LB.CR | 1.1875" | ||||||||
| 175LB.CR | 1.1875" | ||||||||
| STANDARD LENGTH:914.4MM | |||||||||
| THE BOLT HOLES ARE EITHER DRILLED OR PUNCHED,WITH 4 AND 6 HOLES AVAILABLE. | |||||||||
| RAIL SPLICE BAR FOR UIC STANDARD STEEL RAIL | CORRESPONDING RAIL | ||||||||
| SIZE | WEIGHT(KG/M) | DIMENSION(MM) | MATERAIL | SIZE | WEIGHT(KG/M) | STANDARD | |||
| a | b | c | X | ||||||
| U79 | 23.92 | 109 | 27 | 41 | 2.75 | GRADE 700 | UIC54 | 54.43 | UIC |
| 2.75 | |||||||||
| U85 | 29.68 | 121 | 24 | 45 | 2.75 | GRADE 700 | UIC60 | 60.34 | UIC |
| 2.75 | |||||||||
| RAIL SPLICE BAR STANDARD:UIC864-4 STANDARD,UIC864-8 STANDARD | |||||||||
| RAIL SPLICE BAR FOR DIN STANDARD STEEL RAIL | CORRESPONDING RAIL | ||||||||
| SIZE | WEIGTH(KG/M) | DIMENSION(MM) | MATERAIL | SIZE | WEIGHT(KG/M) | STANDARD | |||
| a | b | c | x | ||||||
| y | |||||||||
| F130 | 9.6 | 70 | 16 | 21 | 4.33 | GRADE 700 | S30 | 30.03 | DIN5901 |
| 4.33 | |||||||||
| F133 | 12.7 | 91 | 18 | 20 | 4 | GRADE 700 | S33 | 33.47 | DIN5901 |
| 4 | |||||||||
| F141 | 15.7 | 94 | 20 | 31 | 3 | GRADE 700 | S41 | 41.38 | DIN5901 |
| F149 | 3 | S49 | 49.43 | ||||||
| RAIL SPLICE BAR STANDARD:DIN5902:1995 | |||||||||
