Help CenterMatte pc Graphic Overlay Switch With Lcd Clear Window
Related Products
-
Touch Screen Membrane Switch With Flexible CircuitUS$ 0.2 - 0.36MOQ: 1000 Packs -
Conductive Silver in Printing Circuit Switch With Protective TailUS$ 0.36 - 0.8MOQ: 500 Pieces
-
Line Membrane Switches With Male/female Connector Equivalent to MolexUS$ 0.36 - 0.8MOQ: 500 Pieces
-
LCD Screen Control Panel With Lcd Transparent WindowUS$ 0.36 - 0.8MOQ: 500 Pieces
-
Machinery Touch Control Panel With Red Transparent WindowUS$ 0.4 - 0.8MOQ: 500 Pieces
Specifications
1custom made2 fast delivery
3competitive price
4ISO9001:2008
5PET / PC material
Specifications
Membrane button switch
1. Material: PET
2. Button: embossed dome
3.Viscose: 3 m adhesive
4.excellent quality
5.durable, good click-feeling
passed ISO9001,ROHS,
Technical parameters
Basic Parameter for the Membrane Switch /Membrane keypad /membrane keyboard
Membrane switch is Compositive switch made of insulating material layers and conductive layers. It be comes the first choice for the electric control switch for its unique Superiority. Good appearance, small volum, long life-span and Bend resistance make the membrane switch popularly accepted. Also, it has strong resistances against the water, fire, oil and scratch. Hereby, the basic parameters of it is presented as follows:
Technical Datas
1 Electrical Performance
(1) Operating Voltage: ≤50VD
2) Operating Current: ≤100mA
(3) Contact Resistance: 0.5~10Ω
(4) Insulation Resistance: ≥100MΩ(100VDC)
(5) Base Material Withstand: 2kDVC
(6) Contact bounce: ≤6ms
(7) Loop Resistance: 50Ω,150Ω,350Ω or as per clients’ requirement
2 Mechanical Properties
(1) Life expectancy: >1 million times
(2) Switch stroke: 0.1-0.4mm(Flat type)
0.4-1.0mm(Tactile type)
(3) Actuation force: 15~750g
(4) Flex Tail Pitch(Standard): 2.54 /2.50 /1.27/ 1.25mm
3 Environment Specification
(1) Operation Temperature: -20°C~+70°C
(2) Storage temperature: -40°C~+85°C
(3) Humidity: 40 C, 90%-95%, 240 hours
4 Printing Indicator
(1) Size Deviation: ±0.15mm
(2) Side Boundary: ≤0.1mm
One-stop shopping! Standard and custom-made membrane keypads
XINJIEJIA offers a wide range of standard keypads designed for XINJIEJIA enclosures.When requested, custom-made versions can be supplied at low cost and fast. In addition XINJIEJIA offers the machining of enclosures and mounting of membrane keypads. Keypad face membranes can be designed to your specifications.
Features :
We use exclusively high-quality materials in our membrane keypads, ensuring longevity even in harsh industrial environments.
An overview of our off
You are looking for a membrane keypad with an individual and sophisticated design?
Our keypads are manufactured to meet our customers` exact requirements – whether in terms of size, design or colour, matt, semi-gloss or glossy, with or without a window, with a tactile action point, including LEDs or other components, integrated in supporting plates or pre-mounted on our enclosures.
And of course, assembly of the membrane keypad is part of our service offer.
Commonly used controller for membrane switch
General controller of 2.54 mm and 1.0 mm FPC controller, of course, part of the customer can choose FCI controll
