Help CenterMetal Dome Tactile Membrane Keypad
Related Products
-
Transparent Window Calculator Membrane Keypad With Various of LedsUS$ 0.36 - 1MOQ: 500 Pieces -
Waterproof Transparent Window Electronic Machine Membrane KeypadUS$ 0.36 - 1MOQ: 500 Pieces
-
Digtal Printing PET Membrane KeypadUS$ 0.36 - 1MOQ: 500 Pieces
-
Metal Dome Membrane KeypadUS$ 0.36 - 1MOQ: 500 Pieces
-
Electronic Machine Oilproof Membrane KeypadUS$ 0.36 - 1MOQ: 500 Pieces
Specifications
1 material : PET /PC2 adhesive: 3M467 & 3M468
3 High life time :>1million times
4 Pass:ISO9001:2008RoHS.
Welcome to xinjiejia
Specifications
Membrane button switch
1. Material: PET
2. Button: embossed dome
3.Viscose: 3 m adhesive
4.excellent quality
5.durable, good click-feeling
passed ISO9001,ROHS,
Technical Data
1 Electrical Performance
Operating Voltage |
≤50VD |
Operating Current |
≤100m |
Contact Resistance |
0.5~10Ω |
Insulation Resistance |
≥100MΩ(100VDC) |
Base material Withstand |
2kDVC |
Contact bounce |
≤6ms |
Loop Resistance |
50Ω,150Ω,350Ω or as per clients’ requirement |
2 Mechanical Properties
Life expectancy |
>1 million times |
Switch stroke |
0.1-0.4mm(Flat type)0.4-1.0mm(Tactile type) |
Actuation force |
15~750g |
Flex Tail Pitch(Standard) |
2.54 /2.50 /1.27/ 1.25mm |
3 Environment Specification
Operation Temperature |
-20°C~+70°C |
Storage Temperature |
-40°C~+85°C |
Humidity |
40 C, 90%-95%, 240 hours |
4 Printing Indicator
Size Deviation: ±0.15mm
Side Boundary: ≤0.1mm
One-stop shopping! Standard and custom-made membrane keypads
XINJIEJIA offers a wide range of standard keypads designed for XINJIEJIA enclosures.When requested, custom-made versions can be supplied at low cost and fast. In addition XINJIEJIA offers the machining of enclosures and mounting of membrane keypads. Keypad face membranes can be designed to your specifications.
Features :
We use exclusively high-quality materials in our membrane keypads, ensuring longevity even in harsh industrial environments.
An overview of our off
You are looking for a membrane keypad with an individual and sophisticated design?
Our keypads are manufactured to meet our customers` exact requirements – whether in terms of size, design or color, matt, semi-gloss or glossy, with or without a window, with a tactile action point, including LEDs or other components, integrated in supporting plates or pre-mounted on our enclosures.
And of course, assembly of the membrane keypad is part of our service offer.
Commonly used controller for membrane switch
General controller of 2.54 mm and 1.0 mm FPC controller, of course, part of the customer can choose FCI control
