PE-RT pipe PEX pipe for floor heating
pert pipe pex pipe for floor heating
1.Great resistance
2.Durability and longevity
3.Stable market with BV,ISO,CE
PERT pipes produced by the polyethylene of raw material, transparent for all, is the most common under floor heating pipe at preaent.Pipes nexine is smooth, it can reduce the blocking phenomena by the residuum in the water: good flexibility, easy to install and carry: resistance to low temperature and frost crack, service life up to 50 years.
1) pert pipe for floor heating Features:
1. Good thermal stability and long-term pressure resistance
2. In conformity with potable water hygienic standard
3.Strong impact resistance
4. Good flexibility
5. Easy to be connected (hot-melt connection or mechanical connection)
6.Good thermal conductivity
7.Good processing property
8.Can be recycled, good to the environment.
2) pert pipe for floor heating Specifications(unit:mm):
Nominal outer diameter |
Average outer diameter |
circularity |
series |
||||
S5 |
S4 |
S3.2 |
|||||
minimum |
maximum |
Straight pipe |
Coil pipe |
Pipe wall thickness |
|||
20 |
20.0 |
20.3 |
≤1.0 |
≤1.2 |
2.0 |
2.3 |
2.8 |
25 |
25.0 |
25.3 |
≤1.0 |
≤1.5 |
2.3 |
2.8 |
3.5 |
32 |
32.0 |
32.3 |
≤1.0 |
≤2.0 |
2.9 |
3.6 |
4.4 |
Specification: dn 16-32mm 100m~300m coil length
3) pert pipe for floor heating Choice of S
Design pressure |
Pipe Series S |
||||
20°C 50years σs =7.36MPa |
S1 σs =3.06MPa |
S2 σs =2.15MPa |
S4 σs =3.34MPa |
S5 σs =2.02MPa |
|
0.4 |
6.3 |
6.3 |
5 |
6.3 |
5 |
0.6 |
6.3 |
5 |
3.2 |
5 |
3.2 |
0.8 |
6.3 |
3.2 |
2.5 |
4 |
2.5 |
1.0 |
6.3 |
2.5 |
-- |
3.2 |
-- |
4) pert pipe for floor heating applications:
- Heating system pipelines for floor, wall, roof and street.
- Industrial and residential water system, water supply system of geothermal water
- Pipeline system of pure water, mineral water, drinking water and sanitary water
- Central air-condition pipeline system
5)Company introduction:
