plastic PERT pipe for floor heating system
- 10 Ton / Tons per Month
- qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | dongli | Model Number: | JXPERT |
Specification: | dn16 to dn32 | Length: | 100-300m per coil | Thickness: | 2.3MM |
Standard: | CJ/T175-2002 |
Product Description
Specifications
plastic pipe for floor heatingGreat resistance
Durability and longevity
Stable market with BV,ISO,CE
plastic PERT pipe for floor heating system
plastic PERT pipe for floor heating system
1.Great resistance
2.Durability and longevity
3.Stable market with BV,ISO,CE
PERT pipes produced by the polyethylene of raw material, transparent for all, is the most common under floor heating pipe at preaent.Pipes nexine is smooth, it can reduce the blocking phenomena by the residuum in the water: good flexibility, easy to install and carry: resistance to low temperature and frost crack, service life up to 50 years.
1) plastic PERT pipe for floor heating system Features:
1. Good thermal stability and long-term pressure resistance
2. In conformity with potable water hygienic standard
3.Strong impact resistance
4. Good flexibility
5. Easy to be connected (hot-melt connection or mechanical connection)
6.Good thermal conductivity
7.Good processing property
8.Can be recycled, good to the environment.
2) plastic PERT pipe for floor heating system Specifications(unit:mm):
Nominal outer diameter | Average outer diameter | circularity | series | ||||
S5 | S4 | S3.2 | |||||
minimum | maximum | Straight pipe | Coil pipe | Pipe wall thickness | |||
20 | 20.0 | 20.3 | ≤1.0 | ≤1.2 | 2.0 | 2.3 | 2.8 |
25 | 25.0 | 25.3 | ≤1.0 | ≤1.5 | 2.3 | 2.8 | 3.5 |
32 | 32.0 | 32.3 | ≤1.0 | ≤2.0 | 2.9 | 3.6 | 4.4 |
Specification: dn 16-32mm 100m~300m coil length
3) plastic PERT pipe for floor heating system Choice of S
Design pressure | Pipe Series S | ||||
20°C 50years σs =7.36MPa | S1 σs =3.06MPa | S2 σs =2.15MPa | S4 σs =3.34MPa | S5 σs =2.02MPa | |
0.4 | 6.3 | 6.3 | 5 | 6.3 | 5 |
0.6 | 6.3 | 5 | 3.2 | 5 | 3.2 |
0.8 | 6.3 | 3.2 | 2.5 | 4 | 2.5 |
1.0 | 6.3 | 2.5 | -- | 3.2 | -- |
4) plastic PERT pipe for floor heating system applications:
- Heating system pipelines for floor, wall, roof and street.
- Industrial and residential water system, water supply system of geothermal water
- Pipeline system of pure water, mineral water, drinking water and sanitary water
- Central air-condition pipeline system
5)Company introduction:
Shandong Dongli Plastic Building Materials Co., Ltd. has become one of the leading international manufacturers of plastic pipe and fitting since the foundation in 1999. With an annual production capacity of 250,000 tons, we have more than 2000 employees in 3 factories and strictly follow ISO9001 quality system and ISO14001 environment system to arrange manufacturing.
Due to high-class raw material, strict quality control in both the workshop and laboratory with various professional testing equipment, we promise every single product meets the corresponding inspection standard.
