Home > Instruments & Meters > Test Instrument > Test Machine > Mouse Over Image to Zoom Have One to Sell? Sell it Yourself Fluke 5700A Multi-Function Calibrator 10 Hz to 30 MHz
Mouse Over Image to Zoom Have One to Sell? Sell it Yourself Fluke 5700A Multi-Function Calibrator 10 Hz to 30 MHz
US$ 16,000 - 16,500
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
United States
Brand Name:
Fluke
Model Number:
5700A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fluke 5725A Amplifier 100kHz to 30kHzUS$ 6,999 - 7,000MOQ: 1 Unit -
Rohde & Schwarz SMJ100A / B11/B13/B106/K40/K42/K46 Vector Signal GeneratorNegotiableMOQ: 1
-
Agilent 71200C Modular Spectrum AnalyzerNegotiableMOQ: 1
-
Agilent 3586B-001-004-003 Selective Level MeterNegotiableMOQ: 1
-
Agilent E5061A W/ Opt. 250/100 ENA-L RF Network Analyzer 300KHz to 1.5GHzNegotiableMOQ: 1
Place of Origin
United States
Brand Name
Fluke
Model Number
5700A
Specifications
The 5700A Calibrator is designed to cover the widest portion of today's calibration workloadThe 5700A Calibrator is designed to cover the widest portion of today's calibration workload - a wide variety of DMMs from all manufacturers. It delivers direct voltage to 1100V and alternating voltage from 220V to 1100V at frequencies from 10Hz to 1.2MHz. Cardinal point resistances range from 1-ohm to 100 Mohms in x1 and x1.9 decades, including a short. Direct and alternating current are provided to 2.2 A, and frequencies for alternating current range from 10Hz to 10kHz.
In service since 1988, the 5700A has undergone continuous improvements to become the 5700A Series II, one of the most tested and reliable high precision calibrators Fluke has ever produced. Considered the calibration standard worldwide, the 5700A delivers high value as well as accuracy covering 5 1/2 to 7 1/2 digit dmms. Plus it offers the same ease of use, low cost of ownership, rugged design, simplified support and confidence building features as the 5720A.
Specifications for both the 5700A and 5720A are stated with a choice of confidence levels. Now, you can use the conservative 99% specifications that Fluke traditionally publishes, or more aggressive 95% specifications recommended in many international procedures. In addition to allowing you to trade a small amount of risk for better performance, 95% confidence level specifications allow easier measurement intercomparisons.
Both specifications are available at a press of the SPEC key for any output. Both the 5700A and 5720A can emulate, via the remote interface, either a 5100B or 5200A calibrator, permitting them to replace those older calibrators in automated systems with little or no impact on software. In addition, it is compatible with the 5725A Amplifier, and 5205A or 5215A Precision Power Amplifiers.
