Help CenterConstruction Light Foam Concrete Block, Foam Cement Block, Wall Brick Making Machine
Related Products
-
Light Weight Concrete Cutting Machine With High PrecisinUS$ 8,000 - 20,000MOQ: 1 Set -
Reliable Peformance Foam Generator With Good PriceUS$ 8,000 - 15,000MOQ: 1 Set
-
High Quality Foam Concrete Machine for SaleUS$ 8,000 - 15,000MOQ: 1 Set
-
Small Type Foam Concrete Processing Machine on SaleUS$ 8,000 - 15,000MOQ: 1 Set
-
QTZ80 Tower CraneNegotiableMOQ: 1 Set
Specifications
foam concrete machine1.big capacity
2.high quality
3.light block
4.spots for trial
foam concrete block making machines, wall block shaping equipments, insulation board making machine, cement brick machines, construction block machine
capacity 30 cubic meter per hour
Main Equipment : foamer and mixer, pump
Model |
RF-2000 foamer and mixer |
Output volume |
1500L |
Material input volume |
2000L |
production rate |
15-20m3/h |
Main shaft revolution |
32r/min |
Hopper lifting speed |
22m/min |
Overall dimension |
2600*2250*3000mm |
Total weight |
3200kg |
Mixing motor |
11kw |
Winding motor |
5.5kw |
Water pump motor |
1.1kw |
Vibrating motor |
0.55kw |
Foaming system |
5.5kw |
Model |
RF-30 foam concrete pump |
Max.Output |
30 m3/h |
Max.Conveying Pressure |
8 MPa |
Max.Horizontal Transporting Range |
600 m |
Max. Vertical Transporting Height |
200 m |
Max. Particle Size of Aggregates |
8 mm |
Cylinder Bore |
80mm |
Delivery Cylinder Bore |
140mm |
Max.Pressure of Hydraulic System |
24 MPa |
Oil Pressure Box Volume |
200L |
Motor Power |
30 kw |
Total Weight |
2200kg |
Overall Dimension |
3100*920*1300mm |
Moving Speed |
Less than 8km per hour |
If you are interesting in this machine, please contact with me.
Tel : 0086 371 67670501
