Help CenterPtfe White (F4) Tape
Related Products
Specifications
ptfe white (F4) Tape & Film1.anti-caustic,abrasive resistance
2.thickness:0.1-0.5mm
3.width:10~1500mm
4.any size offer
PTFE TAPE & FILM
Ptfe teflon Skived film
1).thickness : 0.1mm
width:10~500mm
length: unlimited
2). thickness : 0.15mm
width: 10~1000mm
length: unlimited
3). thickness : 0.2~0.4mm
width: 10~1200mm
length: unlimited
4). thickness : 0.5~12mm
width:10~1500mm
length: unliminted
Essential color, -180oC-260oC(no load), ptfe molded and ptfe skived flim.
surface: homogeneous, smooth without rift, crack, air bubble, and mechanical scratch. A few exogenous impurity is permitted.
application: all sorts of corrosive medium.
Property |
Unit |
oriented film |
Skived film |
Tensile strength (min) |
MPa |
≥30.0 |
≥10.0 |
Elongation at rupture |
% |
≥30.0 |
≥100.0 |
1MHz dielectric loss tangent≤0.01mm>0.01mm |
-- |
3.0×104 2.5×104 |
— —
|
1MHz dielectric constant |
-- |
1.8~2.2 |
—— |
|
Dc breakdown voltage (Normal temperature) |
KV/MM |
200 |
40 |
Now available standard of our PTFE skived film
Thickness(mm) |
Width(mm) |
Length(mm) |
0.1 |
10-500 |
unlimited |
0.15 |
10-1000 |
unlimited |
0.2-0.3 |
10-1200 |
unlimited |
Remark: the thinnest thickness is 0.1mm---0.5mm
