Japan imported kubota 10 kw generators for sale
Specifications:
Original Japan Kubota Diesel Generator set 6kw, 8kw, 9kw, 10kw, 12kw, 16kw, 18kw, 25kw, 30kw
Genset Model |
K6 |
K8 |
K9 |
K10 |
K12 |
K16 |
K18 |
K25 |
|
Diesel Engine |
Model |
D905-E2BG1 |
D1105-E2BG |
V1505-E2BG |
D1703-E2BG |
V2203-E2BG |
V2003-T-E2BG |
V3300-E2BG2 |
V3300-T-E2BG2 |
Type |
Four-Stroke, water-cooling, vertical |
||||||||
NO. of Cylinders |
3 |
3 |
4 |
4 |
4 |
4 |
4 |
4 |
|
Bore* Stroke (mm) |
78*78.4 |
78*78.4 |
78*78.4 |
87*92.4 |
87*92.4 |
87*92.4 |
98*100 |
98*100 |
|
Displacement |
1.123 |
1.123 |
1.498 |
1.647 |
2.197 |
2.999 |
3.318 |
3.318 |
|
Air intake mode |
Naturally-Aspriated |
Turbocharged |
Naturally-Aspriated |
Turbocharged |
|||||
Rated Output (kw) |
7.4 |
9.5 |
12.5 |
15 |
20.1 |
22.5 |
28.9 |
35.3 |
|
Rated Speed (rpm) |
1500/1800 |
||||||||
Cooling Method |
Water-cooled with Radiator |
||||||||
Starting Method |
D.C.12V or 24V Electric Radiator |
||||||||
Alternator |
Model (Stamford) |
BCI164A |
BCI164B |
BCI164C |
BCI164D |
BCI184E |
BCI184F |
BCI184G |
BCI184H |
Rated power (KW) |
6 |
8 |
10 |
12 |
16 |
20 |
24 |
30 |
|
Rated Voltage |
220V, 230V, 220V/380V, 230V/400V, ect. |
||||||||
Rated Current |
According to the voltage be selected |
||||||||
Rated Frequency |
50Hz/60Hz |
||||||||
Rated Speed (rpm) |
1500/1800 |
||||||||
Power Factor |
1 for single phase/ 0.8 for three phases |
||||||||
Phase Connection |
Single Phase or Three Phases |
||||||||
Winding Connection |
3 or 4- wire connection (12-wire for 3-phases) |
||||||||
Excitation Method |
Brushless |
||||||||
Voltage Regulation |
AVR |
||||||||
Control Panel |
V-Meter, A-Meter, Frequency Meter, Circuit Breaker, Transfer Switch, AVR, Temp, and Pressure Gauges, Lighter, Hour Meter, Key Starter, ect. |
||||||||
G/N. WET (kg) |
500/450 |
560/500 |
650/600 |
760/700 |
770/710 |
790/730 |
810/750 |
1000/920 |
|
Packing Size (cm) |
185*96*110 |
185*96*110 |
200*96*110 |
200*96*110 |
200*96*110 |
200*96*110 |
230*110*130 |
230*110*130 |
|
Kubota Diesel engine Following :
Kubota Assemberly
Quality control of E.N power Genset
1.The genset canopy can be designed by customers demand free of charge.
2.Noise level can be designed by customer demand, standard noise level is 70-73DB at 7m. Super silent is 60-65DB at7m.
3. Canopy color can be painted free of charge by customer demand. It is high quality paint.
4.All connection components and door lock are stainless steel.
5. We added oil filling inlet with lock
6. The oil box is separate madeand then welded to the base frame, not by simple welding on the base frame. It is to make sure there is no oil leakage
7. The base frame is with forklift mouthwhich is easy to load and discharge
8. For Logo, we can paint customer's logo when the order is more than 5sets.
9. For technical specification or question, we can support you by our strong technical team.
