Introduction of rotary kiln: Rotary kiln is the key equipment in cement industry for calcinating clinker. It is also used in varies industries, such as metallurgy, Chemical, building, rehractory material, environmental production, etc. The kiln is composed of the cylindrical shell, roller supporting device with thrust roller, driving gear unit movable kiln hood, sealing device at kiln inlet, coal dust pipe device etc.
With a certain slope to the level, the whole kiln body is supporting rollers and fitted with thrust rollers to contral up and down movement of the kiln body. Besides main driving unit for driving system, if is also fitted with auxiliary driving unit so as to ensure the kiln could be kiln head sealing adopts housing type sealing and kiln rear uses axial contact sealing unit so that reliability of sealing be ebsures.
Types of rotary kiln:
- Cement kiln;
- Metallurgy chemical kiln;
- Active lime kiln;
- Porcelain kiln according;
- Building material kiln;
- Calcined petroleum coke rotary kiln.
Application of rotary Kiln:
- Rotary kiln is the Thermal Equipment, heating materials, in cement industry for calcining clinker.
- It is also used in various industries, such as cement, nonferrous metallurgy, ferrous metallurgy, chemistry, building, refractory material, environmental protection, etc.
Advantages of rotary kiln:
- High productivity;
- Low heat consumption;
- Stable clinker quality;
- High ecomomic efficiency.
Rotary kiln parameter:
| Specification | Capacity(t/d) | Incline of body(°) | Speed(r/min) | Main motor(kw) | Remarks |
| Φ2.5*60 | 168 | 3.5 | 0.516-1.549 | 75 | Alumyte-alumina forge kiln |
| Φ3*48 | 700 | 3.5 | 0.726-3.63 | 110 | Kiln with 5-stage cyclone precalciner |
| Φ3*60 | 3.5 | 0.492-1.476 | 75 | Alumyte-alumina forge kiln |
|
| Φ3*100.94 | 450 | 4 | 0.3-1.503 | 90 | Multiple-drum cooling |
| Φ3.2*46 | 1000 | 3.5 | 0.36-3.57 | 160 | kiln with preheater precalcine |
| Φ3.2*52 | 1200 | 3.5 | 0.343-0.34 | 125 | kiln with preheater |
| Φ3.3*50 | 1300 | 3.5 | 0.676-3.38 | 160 | kiln with plateau suspension preheater |
| Φ3.3*52 | 1300 | 3.5 | 0.266-2.66 | 125 | kiln with preheater precalcine |
| Φ3.5*54 | 1500 | 3.5 | 0.55-3.4 | 220 | kiln with preheater precalcine |
| Φ3.6*70 | 1800 | 3.5 | 0.25-1.25 | 125 | Generating kiln for using ofterheat |
| Φ4*60 | 2500 | 3.5 | 0.396-3.96 | 315 | kiln with preheater precalcine |
| Φ4.15*58 | 5 | 0.35-0.7 | 110 | Zinc leaching(calcine rotary kiln) | |
| Φ4.2*60 | 3000 | 4 | 0.4-3.98 | 375 | |
| Φ4.3*60 | 3500 | 3.5 | 0.396-3.96 | 375 | kiln with preheater precalcine |
| Φ4.5*66 | 4000 | 3.5 | 0.41-4.1 | 560 | kiln with preheater precalcine |
| Φ4.8*74 | 5000 | 4 | 0.396-3.96 | 630 | kiln with preheater precalcine |
| Φ5.0*74 | 6000 | 4 | 0.35-4 | 710 | kiln with preheater precalcine |
| Φ5.6*87 | 8000 | 4 | Max4.23 | 800 | kiln with preheater precalcine |
| Φ6.0*95 | 10000 | 4 | Max5 | 950*2 | kiln with preheater precalcine |
Rotary kiln pictures:
Rotary kiln manufacturing process:
Rotary kiln consignment and on-site pictures:
a. Installation and adjustment: Should the installation service is needed, technicist will be provided by supplier for buyer to assist the work such as welding connection of shell body.
b. Quality Guarantee: Three-guarantees of product and warranty period is one year.
c. Technical support is provided from the beginning to the end.
d. Spare parts are serviced for sale in the whole year
- Luoyang Zhongde Heavy Industries Co., Ltd, whose predecessor was Luoyang Mining Machinery Cement Equipment Factory, was founded in 1959.
- Over the past fifty years, it has made significant contribution to the economic development in China.
- In 1995, it took the lead in changing into the joint stock company, which brought rapid development to the company .
- In 2006, the old factory relocated into the large modern industrial workshop in Luoxin Industrial Park.
How about the quality of your rotary kiln?
- Our rotary kiln manufactured strictly according to national and international standard.
- We take a test on every rotary kiln before delivery.
How about price of rotary kiln?
- We can give the lowest price of the rotary kiln than market one.
- We do quotation of rotary kiln as soon as possible for any custome.
- Discount of rotary kiln can be given according to quantity.
How about the after-sale service of your company?
- Our engineer is aviliable to installation rotary kiln overseas.
- The guarantee period of our rotary kiln is one year.
