High Speed Roll Up Door Automatic Rolling Door
Rolling door description
Winsion kjm -4000 internal / external rapid rolling doors, there is spring-balance system, lifting speed fast, strong wind resistance, the lighter fabric door curtain, not only beautiful and strong but also withstand greater loads, can separate different temperature zones, to prevent air convection, to ensure the indoor temperature, vermins-proof and dust-proof.
Rolling door advantages over conventional doors:
1. High speed: speed up to 1.5m/s;
2. High frequent used: 1000/1500 times/day;
3. Electronic: automatic open/ close, more convenient;
4. Special function: dust-proof, insect-proof; water-proof, wind-resistant;
5. Appearance: beautiful and simple;
6. Operation direction: vertical up and down, save space;
Rolling door technical parameters:
Appearance: High-strength antioxidant aluminum alloy frame 120 ×130 mm, silver-white, meet the standard 6063-T6, cold rolled steel electrostatic spraying door cover, chassis.
Power performance: Germany SEW brake motor, power 0.55- 1.5KW, power supply 220V/380V, brake voltage is 220V.
Control system: imported microcomputer frequency conversion to control of electric box (Mitsubishi cpu).
Control voltage: safe low-voltage 24VDC.
Opening speed: open 0.8-1.5m / s / off 0.6-1.2m / s (frequency conversion can adjust the speed).
Door curtain material: imported high-density polyester fiber and the surface coating processing, thickness 0.8mm-1.5mm, variety colors can be chose.
Tensile strength: 5700/5100N/5cm, tear strength 900/80N.
Fire-proofing level: German standard MZD / NBL fire resistant.
Usage temperature: -10 ℃ +70 ℃ .
Transparent window: import PVC transparent crystal soft plate, thickness 1.5mm, rectangle or oval.
Wind resistant material: aluminum alloy wind resistant ribs, Sub-section connecting, easy to replace.
Wind resistant capability: 9m / s (50Pa standard 3 × 3).
Sealability: the bottom of the door curtain U-shaped balloon bags can tight fitting with the uneven ground, the seal strip on the both sides of the door can vermins-proof and dust-proof.
Security Configuration: Standard infrared opto-electrical protection, pressure balloon, warning lights, anti- collision column, power failure hand crank.
Rolling door applications:
>Outdoor large warehouses, the outside door of the factories, heavy industry, airports, aerospace industries.
>Separate different temperature zones, the environment need to save energy.
>The place needs to frequently open and close.
Rolling door display:
Company Profile:
Guangzhou Winsion Door Industry Co., Ltd. is specialized in producing roller Soft shutter doors, rapid roll doors, rapid doors, high speed doors, high speed rolling doors, high speed shutter doors, rapid shutter doors, automatic doors, rapid accumulation of doors, free metal doors, Industrial roller shutter doors, sliding doors, pvc transparent soft curtain, transparent soft board, and other aspects of anti-static dust engineering development, design and production and sales of high-tech enterprises, our company has strong strength, and our products are sold throughout all over the world.
