Made-in-China! 25m DFR-825 Full Hydraulic Rotary Auger Drilling Rig
DFR-825 auger drilling rig is designed by DEFY factory based on former DFR-12C. It is a kind of full hydraulic pile driver with rod locking design. More safe and convenient to use.
Structure |
Item |
DFR-825 |
Engine |
Brand |
Cummins |
Model |
6BTAA59-C160 |
|
Rated Power |
118KW/2200r/min |
|
Type |
Intercooled supercharger |
|
Maximum torque |
670N.M |
|
Drilling diameter |
mm |
500-1200 |
Drilling depth |
m |
25 |
Hydraulic system |
Maximum working pressure of the main pump |
|
The maximum flow rate of the main pump |
||
Power head |
Maximum torque |
|
Rotating speed |
||
High-speed rejection soil |
||
Pressurization system |
Maximum pressure force |
110KN |
Maximum lifting force |
110KN |
|
Maximum stroke |
2500mm |
|
Main winch |
Maximum lifting force |
120KN/m |
Maximum lifting speed |
45m/min |
|
Auxiliary winch |
Maximum lifting force |
20KN/m |
Maximum lifting speed |
50m/min |
|
Mast |
Inclination (left and right) |
±4° |
Inclination (Front and back) |
5° |
|
Chassis |
Maximum travel speed |
3.6km/h |
Maximum gradeability |
30° |
|
Track width |
||
Telescopic Crawler |
||
Chassis length |
||
Total Weight |
Ton |
24 |
Transportation dimension |
L*W*H |
11400*2600*3400mm |
Working dimension |
L*W*H |
7500*2600*12500mm |
1. Advanced mobile type, quick to transfer from transportation to working mode.
2. High safety standard, satisfying dynamic and static stability requirements, ensuring safe working.
3. Optimized luffing mechanism, working stable, easy to maintenance.
4. Innovative drilling bucket depth measurement system, showing a higher accuracy than conventional pile driver.
5. Bottoming protection and priority control function of main winch, making it easier to operate.
6. Multi-stage of vibration-proof power head, ensuring it working more stable.
7. Mast can adjust vertical property automatically, making it to drill more precise.
8. Humanized cabin design, with large space.
9. Secondary operating interface, more convenient using.
10. Efficient energy-saving turbocharged water-cooled diesel engine.
11. Excellent fuel system
12. Advanced cooling system
13. Intelligent Control System
1. One year quality guarantee for main machine;
2. Training: operation manual, overseas installation is also available;
3. Spare parts are available in our factory at cost price for former customers;
4. 24 hour on-line guidance for operation and maintenance.
