XY-600C used water well drilling machine is a 600m spindle drilling rig, adopting 53HP diesel engine with electric start, BW-200/250 mud pump for water flushing and cooling drill tools, ten speed adjusment gearbox, hydraulic chuck, integrated drill tower, six wheels, sliding base.
It is widely used for drilling water well, geothermal and irrigation well, geotechnical investigation, mining exploration, bridge building, etc.It can drill soil, sand, gravel, rock, etc.
1. Main Parameters | |||
Max. Drilling Depth |
600m |
||
Diameter of drill pipe |
Φ42,Φ50,Φ60,Φ76 |
||
Angle of vertical spindle |
90°~65° |
||
Drilling capability | |||
Φ75mm drill diameter |
600m depth |
||
Φ127mm drill diameter |
400m depth |
||
Φ219mm drill diameter |
210m depth |
||
Φ273mm drill diameter |
150m depth |
||
2. Vertical Spindle | |||
Rotation speed |
Forward 10 grades |
30-1050r/min |
|
Reverse 2 grades |
29-137r/min |
||
3. Main hoist | |||
Lifting speed of single wire |
0.5-1.9m/s |
||
Diameter of wire rope |
12.5mm |
||
Carry capacity of single wire |
4000kg |
||
4. Mud pump(as per your choice) | |||
Horizontal triplex mud pump |
BW-200 |
||
Displacement |
200L/min |
||
5.Power supply(choose one between the following two) | |||
Diesel engine |
Model 4100,38kw(50HP) |
||
Electrical motor |
Y180M-4B35,22kw |
||
6.Six-wheel Trailer |
|||
Walking speed |
25Km/hr |
||
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Established in 1970s, Zhengzhou Defy has growned into one leading drilling rig manufacturer in China, specilizing in drilling rig technology R&D, manufacturing, etc. We spark on conventional rotary drilling rig, new pneumatic drilling rig and are inventing another drilling rig with performance same as pneumatic one, but with much less investment for users.
Our drilling rigs are widely used for water well drilling, irrigation well drilling, geothermal hole drilling, mining blast hole drilling, construction pile work drilling, air-conditioner hole drilling, etc.
DEFY Brand drilling rigs have been widely exported to Chile, Russia, Australia, Malaysia, Kenya, Tansanzia, Zambia, South America, Peru, Zimbabwe, etc.
Every customer is very welcomed to our factory for visiting driling rig, talking onsite and details. ^_^
How to choose a suitable drilling rig?
1. What will you do using drilling rig?
---For water project, core sample, soil test, mineral prospect or others?
2. The depth you need?
---For water well, generally, 30-200m. For core sample, 30-600m, even more.
3. Any requirements to hole diameter?
---Within a certain range, the smaller diameter, the deeper depth. Mathematically, we call it inversely proportional.
4. Working land condition?
A. soil, sand, weathered land, etc. soft stratum.
B. soil, sand, soft and hard rock stratum, mixed one.
C. Mainly hard rock, like granite.
Based on the above information, DEFY experienced engineers will help you recommend suitable machine and price. If you have special demands, please tell us ahead.
