Solar Inverter Companies

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port shenzhen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	BAYKEE
Model Number	TYN-33	Specification	Normal
Application	Commercial	Output Voltage (V)	380V/400V/415V
Load Power (W)	10KVA~200KVA	Solar Power (W)	10KVA~200KVA
Work Time (h)	24

Product Description

off grid solar systems

Off grid solar system for home:

System Capacity	Solar panel	Battery	MPPT controller	Inverter	Energy Per day	Total price
BKNS-1kw	4pcs 250w24v	4pcs 65AH12V	1pcs 24V40A	800w	4 kw/h
BKNS-2kw	8pcs 250w24v	4pcs 120AH12V	2pcs 24V40A	1.5kw	8 kw/h
BKNS-3kw	12pcs 250w24v	4pcs 200AH12V	1pcs 48V60A	2kw	12 kw/h
BKNS-4kw	16pcs 250w24v	8pcs 200AH12V	2pcs 48V40A	3kw	16 kw/h
BKNS-5kw	20pcs 250w24v	8pcs 200AH12V	2pcs 48V50A	4kw	20 kw/h
BKNS-6kw	24pcs 250w24v	16pcs 200AH12V	2pcs 48V60A	4kw	24 kw/h
BKNS-7KW	28pcs 250w24v	16pcs 200AH12V	3pcs 48V50A	5KW	28 kw/h
BKNS-8KW	32pcs 250w24v	16pcs 200AH12V	3pcs 48V60A	6KW	32 kw/h

TYN series three phase solar UPS

Introductions:

TYN series UPS is professional off grid solar ups,it is not only with the performance of common ups,more important it can be finish the off grid solar system function with baykee PDU.

Work model description;

1,When solar power sufficient,system will turn to solar inverter model automatically;

2,When solar power insufficient, it will limit charge current,delivery the power to load as much as possible;

3,When power of load is greater than or similar to the power that solar absorb, solar ups can choose AC power supplemental priority or battery power supplement,then guarantee the load can work normally:

4,If the AC power is not available (grid power or generator),system will choose battery power to discharge automatically;

When solar power recover, solar ups start automatically, to start the recycle energy conversion;

The special solar ups system from baykee, is one of the most advance system in local market at present. It is not only consider the system balance, also consider the charge and energy transfer in complicated status,this system also is baykee research by ourselves.

Applications:

TYN series solar UPS, champion UPS, industrial UPS from 10KVA to 600KVA ,It's designed specially for data management center, manufacture industry, petrify system, metallurgical industry, power system etc. It's the best protection equipment for various kinds of important equipments. Widely use in: power supply for restaurant,power supply for office use,power supply for factory,power supply for outdoor,power supply for desert middle part.

Main Features:

1. flexible setting energy sequence;

2. AC bypass configuration ;

3. High Efficiency (Up to 95%) ;

4. intelligent distribute load type, improve the use ratio effectively;

5. EPO (Emergency Power Off) ;

6. solar input ,load and charge balance automatically;

7. Low installation and operating costs ;

8. solar energy data is clear at a glance,calculate the energy by solar absorb directly and accurately

9. inverter efficiency is 98% max;

10. LCD shows the solar energy flow chart and data;

11. Low Total Harmonic Distortion Level (THD </= 3%) ;

12. Synchronization Capability with external sources ;

13. 50/60 Hz Frequency Converter version is available ;

14. intelligent generator input compatible, once the system power not enough,send a signal to start generator automatically;

15. Intelligent battery management system extends the lifetime of batteries;

16. Different voltage applications with refer to country mains characteristic.

3. Benefits of Solar Power

Now is a great time to go solar and harvest the power of the sun. Here is our top ten list of the benefits to installing solar power:

When installed, solar energy is free – no resources are consumed
Help to lessen our dependence on heavily polluting coal power stations
Fossil fuels can't last forever, future generations will appreciate the effort
You are gaining energy independence - add battery backup power for even greater energy security
The cost of electricity is only going to rise – insure against that rising cost
Quality solar power and water adds value and appeal to your home
Solar PV systems are easily upgraded in future - aim to make your house a net energy producer!
Solar panels offer a long lifetime of low maintenance service, maybe 30-40 years
Your friends will think you're great!
You'll feel great for doing your bit for the environment!

Features:

High Module Conversion Effiiency
Fast and inexpensive mounting
100% EL testing on every modules
Guarantee positive output tolerance ( 0+3% )
Withstand high wind and Snow Loads
Excellent performance in low light environments

ATTENTION:

Above solar energy system configuration is for reference. It can be adjusted based on actual condition and requirement.

All parts have been tested and proven in actual operation with enough reliability and stability. It’s suggested to source

whole system as a pack from us to guarantee the system compatibility.

NOTES:

1. Power output data is based on areas with daily average peak power sunshine of 5hrs.

2. The battery capacity is designed for power storage of 4~5 Hrs PV output.

3. Mounting racks can be specially designed based on site condition.
