This lathe is a special-purpose vertical lathe and it is suitable for processing the internal/external cylindrical surface, conical surface, end face and so on with large-diameter for all kinds of workpieces . This lathe is reasonable in structure and strong in rigidity with large power and good stability, and what's more, it's beautiful in appearance and easy for operation, really the ideal product for processing all kinds of large-diameter workpieces.
Specifications:
MODEL |
VMC-650 |
VMC-850 |
VMC-950 |
VMC-1060 |
VMC-1155 |
Travel X/Y/Z (mm) |
650/400 /480 |
800/500 /550 |
920/500 /550 |
1000/600 /600 |
1100/550 /600 |
Spindle Nose- Table Surface (mm) |
80-560 |
105-655 |
80-630 |
180-780 |
150-750 |
Spindle-Column Slideway (mm) |
480 |
550 |
515 |
600 |
610 |
Max X/Y/Z Rapid Feed Rate (mm/min) |
12000 |
18000 |
|||
|
Max X/Y/Z Cutting Feed Rate (mm/min) |
6000 |
6000 |
|||
Table Size (mm) |
420X800 |
460X950 |
405X1370 |
600X1300 |
580X1200 |
Table Working Load (kgs) |
600 |
600 |
600 |
800 |
1000 |
T-Slot (No.X size /Distance) (mm) |
3X18/135 |
3X18/150 |
5X16/60 |
5X18/120 |
5X18/120 |
Max Spindle Speed (rpm) |
8000 |
||||
Spindle Taper /Outside Diameter (mm) |
BT40/150 |
||||
Main Motor (Kw) |
5.5/7.5 |
5.5/7.7 |
7.5/11 |
||
Drive Motor Torque X/Y/Z (Nm) |
12/12/12 |
12/12/12 |
12/12/12 |
22/22/22 |
12/16/16 |
Positioning Accuracy (mm) |
±0.005/300 |
||||
Repeating Positioning Accuracy (mm) |
±0.003/300 |
||||
Machine Net Weight (kgs) |
4500 |
5000 |
4500 |
8300 |
7300 |
Dimension (LXWXH cm) |
234X227 X225 |
270X235 X263 |
290X270 X260 |
330X290 X300 |
330X290 X300 |
Qingdao Shengtuo Machine Tool Co.,Ltd is specialied in manufacturing large -diameter surfacing lathes.The major products are heavy duty landing lathes,horizontal lathes,vertical lathes,CNC,heavy duty lathes,flange lathes,roll turning lathes.We owned the certificate of CE and ISO9100.
It is widely applied to many industries,such as rubber machinery,textile machinery,mine machinery,chemical machinery, Air Accessories,paper machinery, Boiler and Pressure Vessel,wind power accessories and other processing various flanges.
1. Are you a factory or trading company ?
RE: Shengtuo was founded in 1998 and has a history nearly 20 years in manufacturing lathes. Through reformation we have been changed from a state-owned enterprise to a joint-stock private enterprise. In 2008, we began to explore overseas market step by step. Gradually, our partners from around the world become more and more. We believe that a brighter further is waiting for us.
2. What's your advantage?
RE: We have strong R&D ability which can support us to offer "Turnkey Engineering Service"
-Technology Assessment;
- Process Analysis
- Jigs planning
- Production process
- Trial cut processing
- Education & Training
- 24hours service
3. Question : Where is your factory located ? How can I visit there ?
RE: We are located in Qingdao City. Which is only 30 minutes away from Qingdao Airport.
