Product Details
| Condition | New | Type | Other, Landing | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 2200mm | Place of Origin | Shandong, China | |
| Brand Name | Qingdao ShengTuo | Model Number | C6022 | |
| Voltage | 380V | Power(W) | 15KW | |
| Dimension(L*W*H) | 3200*2200*2500mm | Weight | 3000kg | |
| Certification | CE ISO9100 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
China Wholesale Supplier LandingLathe Machine for Sell
It is widely applied to many industries,such as rubber machinery, textile machinery,chemical machinery, automobile manufacturing ,tire mould machinery and so on. It is mostly used to process various flanges, valves, pressure vessels, boilers,tire moulds,plastic moulds, boilers and other workpieces.
Specification:
| ST-C6022 | Unit | |
Type of machine | Facing Lathe |
|
|
Max. swing diameter of workpiece | 2200 | mm |
|
The cross-feed travel of slide carriage | 1000 | mm |
|
The longitude-feed travel of slide carriage | 400 | mm |
|
Max. length of workpiece | 700 | mm |
|
Max. weight of workpiece | 4000 | kg |
|
Chuck diameter | 1600 | mm |
|
The quantity of the steel jaws | 4 | set |
|
Number of spindle speeds | 6 | level |
|
Spindle diameter | 190 | mm |
|
Spindle bore | 50 | mm |
|
Cutter bar section size | 50×50 | mm |
|
Spindle speed range | 21~216 | r/min |
|
Power of main motor | 11 | KW |
|
Power of feed motor | 1.1 | KW |
|
Adjusting mode of feed motor | stepless |
|
|
Machine power supply | 380v,50HZ,3P |
| |
Lathe weight | about 7 | t |
|
Standard configuration:1 headstock, 1piece of 4-jaw(500 mm-long per jaw) chuck Φ 1600mm, 1 piece of chuck wrench, 1 bed(1.56m-long), 1 base, 1 main motor(11kw), 1 feed motor. |
| ||
Optional configuration: Extended bed and floor,chuckΦ1400mm,1600mm,1800mm and 2000mm.500mm-long jaws. |
| ||
Specific Notice: Customers can customize the lathes according to their workpieces. |
| ||
Qingdao Shengtuo Machine Tool Co.,Ltd is specialied in manufacturing large -diameter surfacing lathes.The major products are heavy duty landing lathes,horizontal lathes,vertical lathes,CNC,heavy duty lathes,flange lathes,roll turning lathes.We owned the certificate of CE and ISO9100.
It is widely applied to many industries,such as rubber machinery,textile machinery,mine machinery,chemical machinery, Air Accessories,paper machinery, Boiler and Pressure Vessel,wind power accessories and other processing various flange
.
Our Workshop
Our Client

As a professional manufacturer of lathe machines, we want our customers to know of our commitment to providing the latest products to all customers.
1. Are you a factory or trading company ?
RE: Shengtuo was founded in 1998 and has a history nearly 20 years in manufacturing lathes. Through reformation we have been changed from a state-owned enterprise to a joint-stock private enterprise. In 2008, we began to explore overseas market step by step. Gradually, our partners from around the world become more and more. We believe that a brighter further is waiting for us.
2. What's your advantage?
RE: We have strong R&D ability which can support us to offer "Turnkey Engineering Service"
-Technology Assessment;
- Process Analysis
- Jigs planning
- Production process
- Trial cut processing
3. Question :What’s your material your lathe machine?And how was your quality of products?
RE: Our material of lathe is cast iron,which have the function of Fixed and prevent vibration.As for quality I want to tell you the important part is spindle of lathe machine,we used the best durable spindle in China in order to produce heavy workpiece.
4. Question : Where is your factory located ? How can I visit there ?
RE: We are located in Qingdao City. Which is only 30 minutes away from Qingdao Airport.
Our mission:
Shengtuo is committed to bring efficient, high precision and stability to all users by insisting on providing our customers with high quality machines. We got ISO9001 certificate in 2000, CE certificate in 2005 for ensuring the best in quality.
