Diesel Generator Powered by Cummins Engine 6CTA Series

Specifications

Specifications:diesel generator,diesel generator set,generator,silent diesel generator,soundproof generator,weatherproof gen set
1) Output range: 150-175-188-200KVA
2) Engine models: 6CTA8.3-G2, 6CTAA8.3-G
3) Alternator models:
a) Marathon
b) Stamford
c) Engga
4) Small volume, light weight, low noise, low fuel consumption, water-cooling with
water tank and fan
5) Key start / auto start
6) Monitoring meters and control switches
7) Protection provided for short, over-current, over-speed, high water temperature,
and low oil pressure
8) Soundproof / weatherproof canopy optional
9) Standard parts: industrial type silencers, exhaust pipes, flexible exhaust bellows,
vibration-damping rubber, lead-acid batteries, connective cables, user manual
and technical papers

Parameters:
1) Rated voltage: 400 / 230V, 220/127V
2) Rated frequency: 50/60Hz
3) Mode of connection: 3-phase-4-line
4) Rated power factor: 0.8 (lagging)
5) Wave distortion: below 10%
6) Power supply voltage: 24V
7) Volt fluctuation: below 0.5%
8) Voltage / frequency fluctuation: ≤0.5%

Features:
1) Engine:
a) Cummins engines adopted
b) Multi-cylinder in-line engine, 4-stroke, direct injection
c) Naturally aspirated, turbocharged, water cooled or turbocharged with air
intercooler
d) B and C series mechanical governors or other electronic governors
e) PT fuel injection pump
f) Electric motor starting system
g) Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder
liner
h) Low discharge, and low fuel consumption
i) Installed conveniently and maintained easily

2) Alternator:
a) Brushless, self-excited, 4-pole, single bearing
b) AVR self-regulated, voltage regulation rate ≤± 1%
c) IP21 protection grade
d) Class H insulation
e) Radio interference restraining accords with stipulation of VDE0875-N and ISO8528
f) Moistureproof, sand-proof, dustproof, salt-proof and vibration-proof
