33KW Lovol Diesel Generator 1004G

Diesel Generator Set, LOVOL engine, 30kw/38kva

Generator set details:
Generator set Model: FLG33 Prime Power: 33kw/38kva

Standby Power: 33kw/41kva

Demission(mm): 1740*815*112

Weight: 950Kgs

Voltage Regulation≥±5%

Voltage Regulation, stead state: ≥±1%

Sudden voltage warp(sudden reduce): ≤20%

Sudden Voltage warp(sudden reduce): ≤15%

Voltage Stable time(sudden reduce): ≤1.0s

Voltage Stable time(sudden increase): ≤1.0s

Frequency Regulation, stead state: ≤0.5%

Frequency Waving: ≤0.5%

Frequency Recovery time(sudden reduce): ≤1.0s

Frequency Recovery time(sudden increase): ≤1.0s

Engine Data:
Engine Brand: LOVOL 1004G (Tianjin)

Diesel:7.5L/h
Lub oil: 0.08L/h
Max Power: 44kw
No. of Cylinder: 4 in line
Bore*stroke(mm): 100*127
Volumn(L): 3.99

Vent. Vol (m3/min): 60

Air Intake Vol.(m3/min): 2.8

Ex. vol.: 4.3m3/min
Ex. Temp.: 600 degrees
Lub. oil capacity(L): 8.1

Coolant Capacity(L): 21

Alternator data:
Brand: Stamford, ENGGA, Marathon, Leroy Somer
Frequency: 50hz 1500rpm
Voltage:230/400v(adjustable)
Phase: 3phase
Power Factor: 0.8 lagging

Insulation class: H/H

Protection Grade:IP21/23:

Standard accessories of Diesel Generator set:

Standard control panel, exhaust silencer, flexible pipe, battery and battery cables, battery rack, operation manual, and document

Optional accessories of Diesel Generator set:

Intelligence control panel, paralleled control panel, automatic transfer switch(ATS) panel, Automatic remote control panel, water heater, oil-water seperator,intelligent battery charger, sound-proof canopy, weather resistant canopy, fuel tank, trailer
