API 8 1/2" IADC 217newest Steel Tooth Rock Bit Used for Oilfield

API 8 1/2" IADC 217newest Steel Tooth Rock Bit Used for Oilfield thumbnail-1
API 8 1/2" IADC 217newest Steel Tooth Rock Bit Used for Oilfield photo-1
US$ 1,000 - 10,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
HJ, HJ
Model Number:
IADC 217, all IADC code
Contact Supplier Request Quote Chat Now
Hejian Hengji Bit Manufacture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name HJ, HJ
Model Number IADC 217, all IADC code
Type Center Drill Bit
Material Other, High Carbon Steel, Tungsten Carbide
Use Other, Well Drilling, Well Drilling

Specifications

1.best quality for 3"~26"
2.ISO&API
3.high quality, best price
ver all IADC code

1 Specifications:



Size

8 1/2”(215.9MM)

IADC

517

Bearing Type

Elastomer sealed journal bearing

Thread Connection

4 1/2 reg pin

WOB(KN/mm)

0.45~1.0

RPM(r/min)

120~50

Applicable Formations

 medium to hard hardness formations with low compressive strength, such as medium, soft shale, medium soft limestone, medium soft sandstone, medium formation with harder and abrasive interbeds, etc

Circulation system

Mud pump

2.Deatail:



Available sizes:

60mm,65mm,76mm,93mm,95mm,98mm(3 7/8”),101.6mm,114mm,118mm,120mm,127mm(5”)

130.1mm(5 1/8”),133.3mm(5 1/4”),139.7mm(5 1/2”),142.8mm(5 5/8”),149.2mm(5 7/8”)

152.4mm(6”),155.5mm(6 1/8”),158.7mm(6 1/4”),161.9mm(6 3/8”),165.1mm(6 1/2”)

190.5mm(7 1/2”),193.6mm(7 5/8”),200.0mm(7 7/8”)

212.7mm(8 3/8”),215.9mm(8 1/2”),222.2mm8 3/4”)

241.3(9 1/2”),244.4(9 5/8”),250.8(9 7/8”)

269.8(10 5/8”),295.3(11 5/8”)

311.1(12 1/4”),346.0 (13 5/8”),349.2(13 3/4”)

374.6(14 3/4”)

381(15”),393.7(15 1/2”),406.4(16”)

444.5(17 1/2”),508(20”),558(22”),609.6(24”)

660.4(26”)

3.Available models:



Steel tooth

(IADC)

111, 121,131

117,124,126,127,136,137

211,311

216,217, 227

TCI

(IADC)

415,435, 417,437

515,525,535,545, 517,527,537,547

615,625,635,,617,627,637,737

512,522,532,612,622,632,732





FAQ(Frequently Asked Questions)



1. How to order the products?
Answer:
Send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.

2. About lead time and shipping time?
Answer :
The lead time depend on quantity of order. Usually shipped by sea, small order or urgent order we can send you by air after received your agreement.
According the distance from china to your port, usually from China to European about 25 days. To West of American 20 days.

3.Can I expect a quality products?
 Answer :
Yes. All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
