5’’ - 100’’ PP String Wound Filter Cartridge Machine Fully Automatic For Beverage

Technical parameters

1.PP String Wound Filter Cartridge Machine is mainly used in the fields of water purification  Beverage foodstuff chemical greases pharmacies electronics environmental protection etc;

2.it’s a dedicated machine for the winding of different yarns. This machine features novel design  high speed low noise high productivity  and good yarn forming ability

3.When the yarn full buzzer alarms the machine will stop automatically. This machine has many advantage as such as easy operation; convenient and pick yarn change  low energy consumption.

Specification

1.Winding line speed: 40-280m/min  constant line speed is available according to product requirements

2.Max. winding dia.: 200 mm(a diameter slightly above 200mm is available on client’s request)

3.Connecting cable: 4×1.5mm R.S.J.MP

4.Power supply: Our default voltage is three-phase 380V/50HZ  one-phase 220V/50HZ. There will be extra fee if you change the voltage.

5.Motor power: 180W/Spinde 250W/Spindle

6.Motor speed: 2800r/min

7.Winding Frame Material: Polypropylene  stainless steel etc. on customer’s request.

8.Winding Reciprocation Stroke: It’s generally :

   5"(125+2mm) 10"(250+4mm) 20"(500+8mm)

   30"(750+12mm)  40"(1000+16mm)  50"(1250+20mm)

   60"(1500+24mm) 70"(1750+28mm)  80"(2000+32mm)

   90"(2250+36mm) 100"(2500+40mm)

(Other reciprocation strokes are to be available to some degree on client’s request)

Single spindle panel sizes: (W×H)390×308mm.

Machine merits:

1.the motor drives the yarn winding shaft through a magnetic disk instead of through direct connection between them; the motor maintains original running state with the machine is braked to release reels; the tension of the yarn is automatically set to a constant value.

2.the machine speed is easy to regulate; wound yarn’s degree of tension and winding pattern can be easily regulated; the tension to the yarn is automatically set to a constant value.
