25.4mm Gluing Interval Filter Making Machine , Controlled by PLC and Monit for car air filter euipment
- 10 Set / Sets per Month
- NINGBO AND SHANGHAI
- Credit Card PayPal
- ShuoBao stainless steel filter 304/316 with PP filter bag for water pretreatment system
- ShuoBao water filter housing stainless high flow for water pretreatment system
- ShuoBao 1 micron water filter with liquid filter bag for PCB
- Shuobao all size stainless water filter housing for water filtration
- Shuobao International Standard Stainless Steel cartridge filter 304/316
- SUS 304 cartridge filter High-Temperature Resistant Steel
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | CHANGJIANG | Model Number: | CJWG-630-II |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
25.4mm Gluing Interval Filter Making Machine , Controlled by PLC and Monitor
General Description
1. This machine is professionally designed and used for mini-pleating and hot melt dispensing on the fiber glass or polypropylene etc filtration materials.
2. It is able to match different specifications of the filter elements, which is characterized with high productive efficiency and simple operation.
Description
1. This machine equips the cutting and trimming device, which us used to meet different filter specifications.
2. This production line is stainless steel body and aluminum frame, which is strong, nice and long life.
3. Six sets of rollers circling placed on one machine, which is easily to be changed and to meet different specifications.
4. The hot melt melting very fast and the hot melt dispensing amount can be adjusted by the frequency converter.
5. High Productive efficiency and good smoothness.
Introduction
1. This machine is equipped with the paper edge cutting device;
2. The pleating height can be adjusted freely, no need changing the rollers, The servo control system can accurately ensure pleating neatly;
3 . Six options for dispensing: Continuously, separately, two sides, one side, auto and manual;
4 . The running speed of the machine can be regulated easily.
5 . The pleating height adjusted and the front-back movement of the paper collecting system can be regulated easily and steadily;
6 . The convey speed of the system is synchronized by the system through the computer regulation
Specification
Diameter of Element | ≤600mm |
Pleating Height Range | 20mm-100mm(any six sizes among these ranges) |
Product Speed | 4-10m/min |
The Interval of Gluing | 25.4mm |
The number of the Gluing | 2*26line |
Power Supply | 380V/50HZ |
Main Power | 16kw |
Working Air Pressure | 0.6MPa |
M/C Weight | 700kg |
Hot Melt M/C Dimension | 900*1000*1500 |
M/C Dimension | 7500*1050*1500 |
Feature
1.The main machine, conveyer belt and the hot melt applicator are all controlled by the PLC and monitor which is simple operation and fast speed.
2.Both the fiber glass pleating and hot melts dispensing on the same machine. The long conveyer belt and cooling fans are adopted after the pleating system. So to fast drying the hot melt and cut any length.
3.The travel distance of two pleats can be adjusted among certain scopes while hot melt dispensing, which avails the dryness and humidity of the hot melt and good for firmly folded.
Note
Furthermore, we can customize the paper pleating production line of different specifications.
