Help CenterBB1335 Vertical Veneer Slicer Machine For Woodworking
Related Products
-
BB1332T Woodworking Vertical Veneer Slicer Machine For Face VeneerUS$ 10,000 - 50,000MOQ: 1 Set -
BB1332 Woodworking Vertical Veneer Slicer For Face VeneerUS$ 10,000 - 50,000MOQ: 1 Set
-
BB1322T Face Veneer Vertical Slicer MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
BB1326T Woodworking Face Veneer Vertical Slicer MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
BB1342 Woodworking Face Veneer Vertical Veneer Slicer MachineUS$ 10,000 - 50,000MOQ: 1 Set
Specifications
1 max.slicing speed 80pcs/min
2 high efficient easy operation
3 ISO9001
4Max allowed wood size 3300*600mm
WE OFFERING U VERY HEAVY DUTY VERTICLE VENEER SLICER MODEL BB 1335
MODEL |
BB1335 |
Max allowed wood size |
2500*500*500mm/3300x400x500mm |
Size of the planer tool |
3500*200*19mm |
Slicing thickness |
0.2-3mm |
Slicing speed |
18-80pcs/min |
Wood clamping method |
Hydraulic control |
Total power |
49.3kw |
Main motor |
37kw |
Hydraulic motor |
5.5kw |
Feeding motor |
5.5kw servo motor |
Circulating heat water motor |
0.75kw |
Veneer transport motor |
0.55kw |
Size of body(L*W*H) |
6800x5000x3700mm |
Net weight |
24T |
1Main motor adopts frequency motor, with famous brand inverter. Energy can be feed back by the special design, and cutting speed improved to be 80pcs/min
2 To guarantee precise veneer thickness, we use ball screw with servo motor. To avoid veneer scratch we used auto blade back system
3 Use hydraulic system, log clamping become more convenient for operator and improves efficiency
4 Control cabinet is combined with electric and hydraulic system, make it easy for single operator
5 Automatic hydraulic blade holding system, and log holder auto turn back system are fitted there, grinding and replacing the blade become so easy and quickly
6 Heating system in blade holder and press bar, avoids stain in the veneer to improve veneer quality
7 Pneumatic brake systems can stop the machine at any required position, and restart promptly. It is convenient for the operator to adjust the log, and safety also guaranteed
8 Self lubricating center can automatically apply lubricant regularly to every moving mechanism, guarantee movement normally smoothly and precisely.
Online video: /v_show/id_XNTM4MjYwNTI4.html
feeding system/Lubricating center
hydraulic blade holding system
Products Sample:
Working Operation:
Certification:
Payment: 30% by T/T deposit in advance as down payment, balance by T/T before shipment.
Package: Bare packing and fit in container directly.
Delivery: About 50 days after receive the down payment.
Warranty: Machine supplied quality guarantee period is: one year for mechanical parts and three months for electrical parts. Warranty is counting from the date of B/L.
What is the Warranty of machine?
Machine supplied quality guarantee period: one year for mechanical parts and three months for electrical parts. Warranty is counting from the date of B/L.
What is the Max veneer width sliced by machine?
Usually 600, width can reach 1300mm by BB1135B model
Why choose HAOZHONGHAO?
1,Professional: We have more than ten years experiences in exporting high quality woodworking machinery, especially Sanding Machine, Veneer Slicer and Grinder.
2,Excellent: Established in 1958, ISO9001 certificated, cooperative with Italy DMC Company
3,Economial: We offer the good price with great quality because we do high-volume production manufacturer.
4 Location: One hour reach Qingdao port
