Wood Chisel Square Mostising Machine
- Qingdao
- T/T
You May Like
Product Details
| Application | other | |||
| Automatic Grade | Manual | Motor Speed | 2840r/min | |
| Max Processing Width | 22mm | Max Processing Thickness | 100mm | |
| Place of Origin | China | Brand Name | HZH | |
| Model Number | MZ1610 B | Voltage | 380V | |
| Power(W) | 2.2kw | Dimension(L*W*H) | 750*650*1700mm | |
| Certification | ISO9001 |
Product Description
We supply high quality Woodworking Chisel Square Mostising Machine
Model | MZ1610 B |
Max.Slotting Width | 22mm |
Max.Slotting Depth | 110mm |
Spindle Speed | 2840r/min |
Working table tilt | ±30° |
Size of Working Table | 540*225mm |
Max vertical moving distance of working table | 250mm |
Max transverse moving distance of working table | 400mm |
Max longitudinal moving distance of working table | 200mm |
Max distance between working table and drill | 400mm |
Motor Power | 2.2kw |
Overall Dimensions | 750*650*1700mm |
Net Weight | 280kg |
Mortise Brilling tool
