plastic bottle infusion machine
Main Application
1. plastic bottle infusion machine washing, filling and sealing three stations adopt rotary type.
2.The sealing station uses hot-melt welding to seal cap.
3.The machine uses mechanical hand to catch bottles neck for location and handing-over.
4.Any scrape of bottle or bottom is not allowed.
Main Technical Parameters
| Max capacity | 6000 bottles/hour adopt frequency conversion for adjusting speed |
| Specification | 100-1000ml plastic infusion bottles (BOPP bottle or vertical soft bag) and matching plastic cap |
| Bottle-air washing number | 30 |
| Water washing number | 30 |
| filling number | 18 |
| Cap-sealing numbers | 30 |
| Washing effect | Qualified rate of washing ≥99.8% |
| Metering error | ≤±1% |
| Welding effect | After sealing, the deviation between the position of bottleneck and cap≤0.4mm; cap-sealing pass rate≥99.9% |
| Total power | About 20Kw |
| Gas consumption | 0.6Mpa, about 260 m3 /h |
| Water consumption | Purified water≥0.2MPa, about 0.7 m3 /h |
| Overall dimension | (L×W×H) 4500×2000×2200mm |
Work principle
Technical process: air washing (3shifts)---water washing(2shifts)—dry blowing(1 shift)—filling--sealing
1). Bottle-handing method
Synchronous belt transfers with bottle-blowing manipulator.
2). Bottle air washing part
Bottle-entering station of plastic infusion bottles adopts synchronous belt to convey to mechanical hand in washing station.
3) Water washing station
1.After the air washing, Mechanical hand catches bottles by bottleneck and turn 180°down, making bottleneck facing down for washing.
2.Bottle-washing spray needle is equipped for washing, after washing, there are bottle blowing drying station, ensures inside and outside of the bottles without any water drop.
4). Filling station
5).Cap-sealing station
This station is mainly used to weld-sealing the cap of plastic infusion bottle after filling during production. It adopts double heating plate to finish cap’s weld-sealing in non-contact hot-melt type.
- Export available package like the wooden cartoon packing.
- Delivery time: 3 monthes
- We supply the FAT sevice
- We supply the installation and commisiong on site service.
- We supply the trainning service.
- We supply the maintaining serive when need immedietly.
